21
Scroll with the ROTARY ENCODER to go to [MODE: AUTO SENSE / NEW KEY 1: xxxxxx], with the
cursor underlining the letter A. If you need to go to [NEW KEY 2], pressing the ROTARY ENCODER
once more will advance the cursor to the number 1, and turning the encoder will go to number 2.
Pressing the ROTARY ENCODER one more time will advance it to the first character of the six-digit
code, which will flash and change as the encoder is turned.
RF BATTERY AUDIO
MUTE
TRANSMITTER
STATUS
PUSH TO SET
XD-
2.4GHz DIGITAL WIRELESS SYSTEM
MODE: AUTO SENSE
NEW KEY1: xxxxxx
MUTE
SELECT
Note, Two encryption key “slots” are provided on the receiver, so that you can use two encrypted
transmitters at different times with the same receiver – for example, having a handheld and beltpack at
the ready for a receiver. The encryption keys are generated at the transmitter, so they will be different
for each one; use [NEW KEY 1] for the first and [NEW KEY 2] for the second.
The easiest way to transfer the encryption code to the receiver is to have the transmitter nearby (no
more than a few feet away from) the receiver, and put the receiver into encryption mode described
above before generating the code in the transmitter. When the code is displayed in the transmitter
display, press and continue holding the ON/MUTE on the handheld or VALUE on the beltpack to
transmit the code to the receiver; you will see Snd appear in the transmitter display. At the same time,
while on the receiver’s [MODE: AUTO SENSE] page with the cursor on the first digit of the code, press
the ROTARY ENCODER after the transmitter completes transmitting the code to the receiver, then
release the button on the transmitter.
Note, After the transmitter has been set to encryption mode, the main display page will show the letters
CR in place of the normal CH to indicate that transmissions are encrypted.
Alternately, the code can be manually transferred to the receiver. Either write down the code from
the transmitter display and later enter it into the receiver on the [ENCRYPTION] page, or bring the
transmitter to the receiver during the two minutes the code is displayed and manually enter what is on
its display. To manually enter an encryption code from the [MODE: AUTO SENSE / KEY 1 (or 2):
xxxxxx] screen, press the ROTARY ENCODER until it is on the first x character which will flash, and
then turn the ROTARY ENCODER until the desired character appears. Press the encoder again and the
next character can be changed. Continue this process until the last character has been entered, and
then press the ROTARY ENCODER one last time to store the code.
MODE: OFF
NEW KEY1: 54Axxx
Note, Though the direct transmission of the encryption code from the transmitter to the receiver is
faster and secure, since it is done at very low power in close proximity to the receiver, some users may
want to make sure that the code is never transmitted –thus the ability to enter it manually. Also,
for redundancy, in some cases the user might want to have two receivers in place holding the same
encryption code for the transmitter, with the second one as a backup.
To change to a new encryption code, when using a currently encrypted transmitter with another
receiver or desiring a fresh code, first go to the [CRYPTO] page on the transmitter. Using the ON/
MUTE or VALUE button, change the setting from [ON] to [OFF] and press SELECT to cancel the
