Life Fitness MTSRL - Manual (Page 18)

3
5
8
2
9
7
6
1
4
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7521201 WLDMT, MTLE, CAM LEFT
2 2 3102802 NUT, NYLOCK 3/8-16
3 2 3202409 3/8-16 X 1.5 BH SCREW
4 2 7559901 SPACER, MTS, .39 ID X .69 OD X .50
5 1 7522201 PLATE, MTS, SELECTOR, 4 POS
6 2 3239803 3/8-16 X 16 HEX HEAD BOLT
7 1 7436695 PLATE, MTS, BELT CAM ATTACH
8 1 3235801 GRIP, SHADOW GRAY, 2.25"
9 2 3102807 NUT, NYLOCK 3/8-16 LOW HT
Page 18
MTSRL RECIPROCATING LEFT
LEFT CAM ASSEMBLY - 7522101
