22 Finalizing the Installation
© Travis Industries 4060111 100-01174
Log Set Installation
Step 1 - Install the logs
1” to 1-1/2” space
Top View
Place the front logs
on top of the burner.
These bolts insert into
the holes in the logs.
Place the rear log on
the two platforms at
the rear of the firebox.
These pins insert
into the holes in
the log.
Do not place logs
over burner holes.
Note how the front left log is
spaced 1/4” to 3/8” off of the
burner holes.
