LG 15LC1R - Manual (Page 30)

30
Operation
1. Press the MENU button and then use D D / E E button to select the SCREEN menu.
2. Press the G G button and then use D D / E E button to select desired item.
3. Use the F F / G G button to make appropriate adjustments.
• H-position/V-position
Adjusts picture left/right and up/down.
The adjustment ranges of H-Position is 0~100.
(Based on the input mode, the adjustment range may change.)
• Clock
Minimizes any vertical bars or stripes appearing on the screen background.
The adjustment range is 0~100. (Based on the input mode, the adjustment range may change.)
• Phase
Remove any horizontal noise and clear up or sharpen the character images.
The range adjustment is 0~100. (Based on the input mode, the adjustment range may change.)
• Auto-configure
Automatically adjusts the screen position, clock, and clock phase.
(The displayed image will disappear for a few seconds while Auto-configuration is in progress.)
• Reset
Returns to the default settings programmed at the factory; default settings
cannot be changed.
4. Press the ENTER button to save.
- After setup, be sure to select RGB-PC source to see the PC image on TV screen.
Screen Menu Options (15LC1R Screen Menu Options (15LC1R
* * only) only)
SCREEN
To set
Auto configure
Manual configure
Reset
F G Á MENU D
E
H-Position 85 F G
D
E
