Page 3
3
ITEM PART
DESCRIPTION
MODEL
NO.
NO.
NO.
Flanged Elements
7
WATTAGE
208VOLT
240VOLT
480VOLT
PART NO.
PART NO.
PART NO
.
7
3000
ELE2540
ELE2531
ELE2532
7
4000
ELE2534
ELE2540
ELE2541
7
4500
ELE2537
ELE2543
ELE2544
7
5000
ELE2533
ELE2534
ELE2535
7
6000
ELE2536
ELE2537
ELE2538
7
WATTAGE
208VOLT
240VOLT
380VOLT
415VOLT
480VOLT
600VOLT
PART NO.
PART NO.
PART NO
PART NO.
PART NO.
PART NO.
7
12000
ELE2558
ELE2557
ELE2564
ELE2561
ELE2558
ELE2579
7
15000
ELE2555
ELE2554
ELE2563
ELE2560
ELE2553
ELE2578
7
18000
ELE2552
ELE2551
ELE2559
ELE2562
ELE2550
ELE2577
Fuses
10
FUS2504
FUSE, 600V 15A (PRIMARY CONTROL CIRCUIT)
ALL 380, 415, 480 & 600V
10
FUS2512
FUSE, 250V 15A (PRIMARY CONTROL CIRCUIT)
ALL 240 & 208V
11
FUS2527
FUSE, 250V 15A (SECONDARY CONTROL CIRCUIT)
ALL
12
FUS2517
FUSE, 300V 40A
208V: 18-72, 108-594KW
12
FUS2516
FUSE, 250V 35A
240V: 18-72, 108-594KW
12
FUS2508
FUSE, 600V 35A
408V & 600V: 18-36, 144, 180-252,
288, 342-360, 396-414, 450-468,
504-522, 558-576, 612-630, 666-684,
720-738, 774-792, 828-846, 882-900KW
12
FUS2510
FUSE, 600V 50A
480V & 600V: 54, 108, 162, 216, 324,
378, 432, 486, 540, 594, 648, 702,
756, 810, 864KW
12
FUS2522
FUSE, 600V 60A
480V & 600V: 90 & 270KW
12
FUS2523
FUSE, 250V 60A
208V & 240V: 90KW
Miscellaneous
8
BLT1018
BOLT, ELEMENT
ALL FOUR BOLT FLANGED
9
GKT2512
GASKET, FLANGED
ALL FOUR BOLT FLANGED
9
GKT2435
GASKET, ELEMENT SCREW-IN
ALL SCREW-IN
13
GTP2003
TEMPERATURE & PRESSURE GAUGE
OPTIONAL
14
MSC2547
HANDLE, DOOR
ALL
15
MSC2546
HINGE
ALL
16
MSC2566
LOCK, KEY
ALL
24
WTR2528
RELAY, LWCO
OPTIONAL
25
WTR2532
PROBE, LWCO
OPTIONAL
26
PRS2008
SWITCH, HIGH WATER PRESSURE
OPTIONAL
-
PRS2507
SWITCH, LOW WATER PRESSURE
OPTIONAL
27
MSC2525
SAFETY DOOR INTERLOCK
OPTIONAL
28
MSC2526
LIGHT, PILOT
OPTIONAL
29
MSC2017
PILOT SWITCH WITH LIGHT
ALL
30
RLV2008
RELIEF VALVE 125# W.P.
ALL
30
RLV2007
RELIEF VALVE 150# W.P.
OPTIONAL
TP0010PBF
PUMP
HHP
GKT1015
GASKET, HAND HOLE 4"X6", ONE BOLT
OPTIONAL
GKT2516
GASKET, MANWAY 11"X15"
OPTIONAL
GKT2520
GASKET, MANWAY 12"X16"
OPTIONAL
MSC2511
ALARM BELL
OPTIONAL
GKT2101
GASKET, SIX BOLT ASME
ALL
MSC2115
COVER, CLEANOUT SIX BOLT ASME
ALL
MSC2505
BLOCK-OFF PLATE, ELEMENT ACCESS SCREW-IN TYPE
ALL
Screw-In Type Elements – 1 1/2” NPS
