2
ITEM PART DESCRIPTION MODEL
NO. NO. NO.
Anode Rods
1 WTR2501 ANODE ROD 1" NPT X 36" LONG 500 & 600 (3 REQ)
1 WTR2502 ANODE ROD 1" NPT X 48" LONG 150 ( 1 REQ)
1 WTR2503 ANODE ROD 1" NPT X 62" LONG 200, 250, 300 (1 REQ)
1 WTR2504 ANODE ROD 3/4" NPT X 52" LONG 400 (2 REQ)
Fuse Blocks
2 BLK2533 FUSE BLOCK, (PRIMARY CONTROL CIRCUIT) ALL 380, 415, 480 & 600V
2 BLK2536 FUSE BLOCK, (PRIMARY CONTROL CIRCUIT) ALL 208 & 240V
3 BLK2535 FUSE BLOCK, (SECONDARY CONTROL CIRCUIT) ALL
4 BLK2508 FUSE BLOCK ALL 208 & 240V
4 BLK2509 FUSE BLOCK ALL 380, 415, 480 & 600V
Terminal Blocks
5 BLK2517 TERMINAL BLOCK 240V: 18-36KW
208V: 18-36KW
408V: 18-54, 72-90KW
5 BLK2518 TERMINAL BLOCK 240V: 54KW
208V: 54, 108KW
480V: 252-270KW
5 BLK2524 TERMINAL BLOCK 240V: 72-90, 108-594KW
208V: 72-90, 144-594KW
480V: 108, 288-900KW
5 BLK2578 TERMINAL BLOCK 480V: 108KW
5 BLK2521 TERMINAL BLOCK 480V: 144-162KW
Contactors
6 CTR2506 CONTACTOR 50 AMP ALL
Thermostats
17 TST2527 THERMOSTAT, SURFACE W/ ECO ALL SURFACE THERMOSTATS
18 TST2573 BRACKET, THERMOSTAT MOUNTING ALL SURFACE THERMOSTATS
19 TST2528 THERMOSTAT, IMMERSION OPTIONAL
20 TST2574 KNOB, THERMOSTAT IMMERSION OPTIONAL
21 TST2576 BRACKET, THERMOSTAT MOUNTING (IMMERSION) OPTIONAL
22 HLC2508 HI LIMIT ALL IMMERSION THERMOSTATS
- RLY2540 SEQUENCER OPTIONAL
Transformers
23 TRF2511 TRANSFORMER, 240/480-120V UP TO 100VA
23 TRF2510 TRANSFORMER, 240/480-120V 101-150VA
23 TRF2502 TRANSFORMER, 240/480-120V 151-250VA
23 TRF2524 TRANSFORMER, 240/480-120V 251-350VA
23 TRF2521 TRANSFORMER, 380/208-120V UP TO 100VA
23 TRF2525 TRANSFORMER, 380/208-120V 101-250VA
23 TRF2530 TRANSFORMER, 415/600-120V UP TO 50VA
23 TRF2531 TRANSFORMER, 415/600-120V 51 - 250VA
