Safety and
Your Fireplace
To prevent severe burns and injuries, install
a screen or physical barrier to prevent direct
contact with the glass .
To order a FREE Lennox
®
SAFETY GUARD
for your fireplace, see details at left.
Follow the safety instructions below
and be sure everyone in your household
understands this burn hazard:
• The surfaces on your fireplace get
EXTREMELY HOT!
• The glass on the front
of the fireplace reaches
EXTREMELY HIGH
temperatures and can cause severe
burns if touched.
• Keep children away from an operating
fireplace. Closely supervise children in
any room where a fireplace is operating
to prevent contact with glass.
• Keep clothing, furniture,
gasoline, and other
flammable liquids away
from the fireplace.
• Even after the gas is turned off, fireplace
surfaces remain extremely hot.
Read Important Safety Information on
Page 4 .
All parts of your Lennox
Hearth Products fireplace
get EXTREMELY HOT!
Thank you for your purchase . We appreciate your business!
Please carefully read and follow all instructions in this manual .
Pay special attention to all warnings and safety information.
Following these safety, care, and operation instructions will help
ensure many years of dependable and enjoyable service from
your fireplace .
Safety and Your Fireplace . . . . . . 2-3
Important Safety Information . . . . . . 4
Appliance Installation, Service, and
Maintenance Notices . . . . . . . . . . . .5
Appliance Operation Notices . . . . . . . 5
Warranty Information . . . . . . . . . . . . . 5
General Information . . . . . . . . . . . . 5-6
Packaging List . . . . . . . . . . . . . . . . . . 7
Appliance Specifications . . . . . . . . . . 7
Unpacking the Appliance . . . . . . . . . . 7
Burn-in Period . . . . . . . . . . . . . . . . . . 7
Codes, Massachusetts and New York 7
Combustion And Ventilation Air . . . . . 8
Site Requirements . . . . . . . . . . . . . . . 9
Clearances . . . . . . . . . . . . . . . . . . . . . .9
Gas Supply Routes . . . . . . . . . . . . . . 10
Preparing The Appliance . . . . . . . . . 10
Mounting The Appliance . . . . . . . . . 11
Fitting the Surround Assembly . . . . . 12
Checking The Burner . . . . . . . . . . . . 13
Connecting A Gas Line . . . . . . . . . . . 13
Checking The Gas Connections . . . . 13
Gas Pressure Check . . . . . . . . . . . . . 14
Spark Gap . . . . . . . . . . . . . . . . . . . . 14
Briefing The Customer . . . . . . . . . . . 14
Servicing . . . . . . . . . . . . . . . . . . . . . 15
Catalysts . . . . . . . . . . . . . . . . . . . . . 16
Testing For Firebox Leakage . . . . . . . 16
Lighting Instructions & Turning Off
Appliance . . . . . . . . . . . . . . . . . . . 17
Troubleshooting Guide . . . . . . . . . . . 18
Replacement Parts List . . . . . . . . . . 19
Positioning of Field Assembled Parts 20
Accessories . . . . . . . . . . . . . . . . . . . 21
Gas Entry Point Dimensions . . . . . . 22
Product Reference Information . . . . 24
TABLE OF CONTENTS
•
FREE
SAFETY
GUARD
OFFER
•
The Lennox
®
SAFETY GUARD protects against
severe burns and injuries by preventing direct contact
with the front glass surface of your fireplace.
To receive your FREE SAFETY GUARD, call 1-800-786-7976
or visit www.lennox.com
(Lennox Hearth Products / Owner Resources)
Note: Safety Guards may not be available for some
older models, that are no longer in production .
