Land Pride Support Stand LR25 - Manual (Page 2)

Land Pride
Listing of Parts
Manual No. 301-222M 3/01/06 2
Qty. Part No. Part Description
Qty. Part No. Part Description
■
1 300-193H RB/LR15 SUPPORT STAND WELDMENT
1 300-194H RB/LR 15/25 STAND BRCKT WLDMT
2 802-034C HHCS 1/2-13X1 1/4 GR5
2 803-019C NUT LOCK 1/2-13 PLT
1 805-161C PIN ROLL 3/8 X 1 3/4 LG PLT
1 805-065C PIN WIRE RETAINING 1/4 X 1 3/4
300-195A RB/LR15 SUPPORT STAND
1 300-171H RB/LR25 SUPPORT STAND WELDMENT
1 300-194H RB/LR 15/25 STAND BRCKT WLDMT
2 802-034C HHCS 1/2-13X1 1/4 GR5
2 803-019C NUT LOCK 1/2-13 PLT
1 805-161C PIN ROLL 3/8 X 1 3/4 LG PLT
1 805-065C PIN WIRE RETAINING 1/4 X 1 3/4
300-196A RB/LR25 SUPPORT STAND
