Chapter 3
Advanced Configuration
10 Wireless-N Access Point with Dual-Band
ADDBA Timeout This option defines the duration
after which the ADDBA setup is terminated, if there are
no frame exchanges within this duration by the Block
Acknowledgement (ACK) agreement. The range is 0 to
65535 ms. The default is 0, which disables the timeout.
Aggregation Window Size This option defines the
maximum number of packets transmitted without getting
ACKs. The range is 0 to 64. The default is 64.
CW Min for STA This option defines the minimum
contention window limit from which the random backoff
is computed for an STA in BSS. The value is set to 7 (default)
and cannot be changed.
CW Max for STA This option defines the maximum
contention window limit from which the random backoff
is computed for an STA in BSS. The value is set to 15
(default) and cannot be changed.
AIFSN for STA This option defines the Arbitration
Interframe Space Number for an STA in BSS. The range is 0
to 15. The default is 2.
TXOP for STA This option defines the Transmission
Opportunity for an STA in BSS. The range is 0 to 8192. The
default is 3008.
CW Min for AP This option defines the minimum
contention window limits from which the random backoff
is computed for AP. The value is set to 7 (default) and
cannot be changed.
CW Max for AP This option defines the maximum
contention window limits from which the random backoff
is computed for AP. The value is set to 15 (default) and
cannot be changed.
AIFSN for AP This option defines the Arbitration
Interframe Space Number for AP. The range is 0 to 15. The
default is 1.
TXOP for AP This option defines the Transmission
Opportunity for AP. The range is 0 to 8192. The default is
3008.
Click Save Settings to apply your changes, or click Cancel
Changes to cancel your changes.
Voice
Use Aggregation This option defines whether or not the
Media Access Control (MAC) layer will set up an Add Block
Acknowledgement (ADDBA) session. The default is Yes.
Select No to disable this option.
Accept Aggregation This option defines whether or not
the MAC layer will accept an ADDBA request. The default
is Yes. Select No to disable this option.
Max. Number of Packets in Aggregation This option
defines the maximum number of packets (sub-frames) in
the aggregate. The range is 0 to 2. The default is 2.
Max. Aggregation Size This option defines the
maximum size of the aggregate (in bytes). The range is 0
to 16000. The default is 10000.
Timeout Interval This option defines the timeout period
in which the aggregate should be closed with a “closing
condition” before it is closed by the timer. The range is 0 to
100 ms. The default is 10.
Min. Size of Packet in Aggregation This option defines
the minimum size (in bytes) of packets to be accumulated
in the aggregate. The range is 0 to 1500. The default is 10.
ADDBA Timeout This option defines the duration
after which the ADDBA setup is terminated, if there are
no frame exchanges within this duration by the Block
Acknowledgement (ACK) agreement. The range is 0 to
65535 ms. The default is 0, which disables the timeout.
Aggregation Window Size This option defines the
maximum number of packets transmitted without getting
ACKs. The range is 0 to 64. The default is 64.
CW Min for STA This option defines the minimum
contention window limit from which the random backoff
is computed for an STA in BSS. The value is set to 3 (default)
and cannot be changed.
CW Max for STA This option defines the maximum
contention window limit from which the random backoff
is computed for an STA in BSS. The value is set to 7 (default)
and cannot be changed.
AIFSN for STA This option defines the Arbitration
Interframe Space Number for an STA in BSS. The range is 0
to 15. The default is 2.
TXOP for STA This option defines the Transmission
Opportunity for an STA in BSS. The range is 0 to 8192. The
default is 1504.
CW Min for AP This option defines the minimum
contention window limits from which the random backoff
is computed for AP. The value is set to 3 (default) and
cannot be changed.
CW Max for AP This option defines the maximum
contention window limits from which the random backoff
is computed for AP. The value is set to 7 (default) and
cannot be changed.
AIFSN for AP This option defines the Arbitration
Interframe Space Number for AP. The range is 0 to 15. The
default is 1.
TXOP for AP This option defines the Transmission
Opportunity for AP. The range is 0 to 8192. The default is
1504.
Click Save Settings to apply your changes, or click Cancel
Changes to cancel your changes.
