GENERAL DESCRIPTION
MAGNUM 300 & 400
Description
Gun Contact Tips Gas
Product Cable Wire Size Standard Diffuser Gas Cable Gun Tube
Number Length (m) in. (mm) Duty Assembly Nozzle Insulator Liner 60°
K541-1 10 ft. .035 (0.9) KP2020-1B1
(3.0) .045 (1.2) -2B1 KP2024-1 KP1932-1 KP2023-1 KP1933-1 KP1928-2
K541-2 12 ft. .035 (0.9) KP2020-1B1
(3.6) .045 (1.2) -2B1 KP2024-1 KP1932-1 KP2023-1 KP1933-1 KP1928-2
K541-3 15 ft. .035 (0.9) KP2020-1B1
(4.5) .045 (1.2) -2B1 KP2024-1 KP1932-1 KP2023-1 KP1933-1 KP1928-2
MAGNUM 400 SHORT NECK (400 amperes at reduced duty cycle) 40% WITH CO
2
GAS*
* May also be used with other gases at reduced rating (up to 30%)
* May also be used with other gases at reduced rating (up to 30%)
Description
Gun Contact Tips Gas
Product Cable Wire Size Heavy Diffuser Gas Cable Gun Tube Feeder**
Number Length (m) in. (mm) Duty Assembly Nozzle Liner 60° Type
K541-21 15 ft. .035 (0.9) KP2021-1B1 Miller
(4.5) .045 (1.2) -2B1 KP2024-1 KP1930 -2 KP1933-1 KP1928-2 K466-3
K541-22 15 ft. .052 (1.3) KP2021-3B1 Miller
(4.5) 1/16 (1.6) -4B1 KP2024-1 KP1930 -2 KP1933-2 KP1928-2 K466-3
K541-23 15 ft. .035 (0.9) KP2021-1B1 Lincoln
(4.5) .045 (1.2) -2B1 KP2024-1 KP1930 -2 KP1933-1 KP1928-2 K466-1
K541-24 15 ft. .052 (1.3) KP2021-3B1 Lincoln
(4.5) 1/16 (1.6) -4B1 KP2024-1 KP1930 -2 KP1933-2 KP1928-2 K466-8
K541-25 15 ft. .035 (0.9) KP2021-1B1 Tweco
(4.5) .045 (1.2) -2B1 KP2024-1 KP1930 -2 KP1933-1 KP1928-2 K466-2
K541-26 15 ft. .052 (1.3) KP2021-3B1 Tweco
(4.5) 1/16 (1.6) -4B1 KP2024-1 KP1930 -2 KP1933-2 KP1928-2 K466-2
MAGNUM 400 SHORT NECK COMPLETE ASSEMBLY WITH FEEDER CONNECTOR (400 amperes) @ 40% WITH CO2 GAS *
** Feeder Kits installed on the gun at the factory.
