GENERAL DESCRIPTION
MAGNUM 300 & 400
Description
Gun Contact Tips Gas
Product Cable Wire Size Standard Diffuser Gas Cable Gun Tube
Number Length (m) in. (mm) Duty Assembly Nozzle Insulator Liner 60°
K471-21 15 ft. .035 (0.9) KP2020-1B1
(4.5) .045 (1.2) -2B1 KP2024-1 KP1932-1 KP2023-1 KP1933-1 KP1928-2
K471-22 15 ft. .052 (1.3) KP2020-3B1
(4.5) 1/16 (1.6) -4B1 KP2024-1 KP1932-1 KP2023-1 KP1933-2 KP1928-2
K471-23 15 ft. 1/16 (1.6) KP2020-4B1
(4.5) 5/64 (2.0) -5B1 KP2024-1 KP1932-1 KP2023-1 KP1933-3 KP1928-2
MAGNUM 400 COMPLETE ASSEMBLY WITH TWECO CONNECTOR (400 amperes) AT 60% DUTY CYCLE WITH CO
2
GAS*
* May also be used with other gases at reduced rating (up to 50%)
A-3 A-3
Description
Gun Contact Tips Gas
Product Cable Wire Size Standard Diffuser Gas Cable Gun Tube
Number Length (m) in. (mm) Duty Assembly Nozzle Insulator Liner 60°
K471-1 10 ft. .035 (0.9) KP2020-1B1
(3.0) .045 (1.2) -2B1 KP2024-1 KP1932-1 KP2023-1 KP1933-1 KP1928-2
K471-7 12 ft. .035 (0.9) KP2020-1B1
(3.6) .045 (1.2) -2B1 KP2024-1 KP1932-1 KP2023-1 KP1933-1 KP1928-2
K471-2/ 15 ft. .035 (0.9) KP2020-1B1
K2286-1
∆
(4.5) .045 (1.2) -2B1 KP2024-1 KP1932-1 KP2023-1 KP1933-1 KP1928-2
K471-10 20 ft. .035 (0.9) KP2020-1B1
(6.1). 045 (1.2) -2B1 KP2024-1 KP1932-1 KP2023-1 KP1933-1 KP1928-2
K471-13 25 ft. .035 (0.9) KP2020-1B1
(7.6) .045 (1.2) -2B1 KP2024-1 KP1932-1 KP2023-1 KP1933-1 KP1928-2
K471-3 10 ft. .052 (1.3) KP2020-3B1
(3.0) 1/16 (1.6) -4B1 KP2024-1 KP1932-1 KP2023-1 KP1933-2 KP1928-2
K471-8 12 ft. .052 (1.3) KP2020-3B1
(3.6) 1/16 (1.6) -4B1 KP2024-1 KP1932-1 KP2023-1 KP1933-2 KP1928-2
K471-4 15 ft. .052 (1.3) KP2020-3B1
(4.5) 1/16 (1.6) -4B1 KP2024-1 KP1932-1 KP2023-1 KP1933-2 KP1928-2
K471-11 20 ft. .052 (1.3) KP2020-3B1
(6.1) 1/16 (1.6) -4B1 KP2024-1 KP1932-1 KP2023-1 KP1933-2 KP1928-2
K471-14 25 ft. .052 (1.3) KP2020-3B1
(7.6) 1/16 (1.6) -4B1 KP2024-1 KP1932-1 KP2023-1 KP1933-2 KP1928-2
K471-5 10 ft. 1/16 (1.6) KP2020-4B1
(3.0) 5/64 (2.0) -5B1 KP2024-1 KP1932-1 KP2023-1 KP1933-3 KP1928-2
K471-9 12 ft. 1/16 (1.6) KP2020-4B1
(3.6) 5/64 (2.0) -5B1 KP2024-1 KP2023-1 KP2023-1 KP1933-3 KP1928-2
K471-6 15 ft. 1/16 (1.6) KP2020-4B1
(4.5) 5/64 (2.0) -5B1 KP2024-1 KP2023-1 KP2023-1 KP1933-3 KP1928-2
K471-12 20 ft. 1/16 (1.6) KP2020-4B1
(6.1) 5/64 (2.0) -5B1 KP2024-1 KP1932-1 KP2023-1 KP1933-3 KP1928-2
K471-15 25 ft. 1/16 (1.6) KP2020-4B1
(7.6) 5/64 (2.0) -5B1 KP2024-1 KP1932-1 KP2023-1 KP1933-3 KP1928-2
MAGNUM 400 (400 amperes)AT 60% DUTY CYCLE WITH CO
2
GAS*
* May also be used with other gases at reduced rating (up to 50%)
∆K2286-1 Magnum 400 Gun has a factory installed feeder end connector.
