Assembly
Step 6
Bolt one M8 crossbar between each wheelbase. This
crossbar is being assembled temporarily to create a
support base and will be removed at a later step.
For outdoor tables only: slide the shimpad onto wheelbase
(steps B, C, and D).
The assembly thus far should match photo E.
A
B
C
D
E
M8 threads
M6 threads
12
2 Required
m8x45
