14
SPECIFICATIONS
MODEL / SIZE CH0030SQB / 30”
CH0036SQB / 36"
CH0042SQB / 42”
CH0048SQB / 48”
COLOR # 304 Commercial Grade Stainless Steel
CONSUMPTION / AMPERE CH0030SQB – 205W / 1.83A
CH0036SQB – 205W / 1.83A
CH0042SQB – 230W / 2.05A
CH0048SQB – 320W / 2.90A
VOLTAGE 120V 60Hz
NUMBER OF MOTORS 1 – 30”, 36”, 42”
2 – 48”
DESIGN 18-Gauge Seamless / Satin Finish
FAN TYPE: CENTRIFUGAL Squirrel Cage
EXHAUST Top 6” Round x 1 – 30”, 36”, 42”
Top 6” Round x 2 – 48”
7” Round Adapter
CONTROLS Electronic Control (4 Buttons) –
10-Second Standby Startup
30-Second Delay Shutoff
HALOGEN LIGHTS 12V 20W x 2 – 30”, 36”
12V 20W x 3 – 42”, 48”
HOOD DIMENSION
(W x D x H) (CH0030SQB) 29-3/4” x 24” x 18”
(CH0036SQB) 35-3/4” x 24” x 18”
(CH0042SQB) 41-3/4” x 24” x 18”
(CH0048SQB) 47-3/4” x 24” x 18”
OPTIONAL ACCESSORIES
(W x D x H) 1) Original Kit - Duct Cover:
Model No. CH0030DC-12 30” x 12” x 12”
Model No. CH0036DC-12 36” x 12” x 12”
Model No. CH0042DC-12 42” x 12” x 12”
Model No. CH0048DC-12 48” x 12” x 12”
2) Recirculating Kit - Recirculating Duct Cover:
Model No. CH0030RD-12 30” x 12” x 12”
Model No. CH0036RD-12 36” x 12” x 12”
Model No. CH0042RD-12 42” x 12” x 12”
Model No. CH0048RD-12 48” x 12” x 12”
3) Model No. SSP30
30” Stainless Steel Back Panel 30” x 1/10” x 32”
4) Model No. SSP36
36” Stainless Steel Back Panel 36” x 1/10” x 32”
Net Gross
(CH0030SQB) 62.0 75.0
(CH0036SQB) 70.0 86.0
(CH0042SQB) 81.0 99.0
HOOD WEIGHT (lbs)
(CH0048SQB) 88.0 114.0
SPEED QuietMode     Low Medium High
Air Capacity (cfm)* (1 Motor/ 2 Motors) 280 / 400 420 / 600 580 / 800 760 / 1000
Sone (1 Motor / 2 Motors) 1.2* / 2.8 2.0 / 4.0 2.8 / 5.6 4.5 / 8.0
*In House Test Static Pressure “0”. One sone is equivalent to the sound of a refrigerator at 40 decibels.
**Specifications subject to change without notice.
