— 32 — — 32 —
P.CONT
ANT.
CONT.
ILLUMI
FRONT • L
FRONT • R
REAR • L
REAR • R
– +
Wiring harness
(Accessory1)
25
29
White/Black
32
Gray/Black
35
Green/Black
38
Purple/Black
White
31
Gray
34
Green
37
Purple
40
To front left
speaker
30
To front right
speaker
33
To rear right
speaker
39
To rear left
speaker
36
Ignition wire (Red) 20
Battery wire (Yellow) 21
Ground wire (Black) · (To car chassis) 22
Ignition key
switch
10
Car fuse box
(Main fuse)
11
ACC 13
Car fuse
box
14
Battery 12
If no connections are made, do not let the wire come out from the tab. 4
Power control wire (Blue/White) 15
Motor antenna control wire (Blue)
17
Dimmer control wire (Orange / White)
(KRC-765 only)
18
5 When using the optional power amplifier,
connect to its power control terminal.
To car light control switch
8
7 Depending on what antenna you are using,
connect either to the control terminal of the
motor antenna, or to the power terminal for
the booster amplifier of the film-type antenna.
Connecting Wires to Terminals (KRC-765 / KRC-665)
FM/AM antenna input 1
Front left output (White) 23
Front right output (Red) 28
Fuse (10A) 24
Rear left output (White) 26
Rear right output (Red) 27
To KENWOOD disc changer/
DAB control input/
KPA-SD100/KPA-HD100/KPA-SS100
16
To connect these leads, refer
to the relevant instruction
manuals.
17
