17
KEY # PART # DESCRIPTION QTY KEY # PART # DESCRIPTION QTY
1 UP 3K ASSB 4" UPRIGHT ASSEMBLY D. GRY 1 53 08-0004 CIRCUIT BREAKER 15 AMP 1
2 DECK ASSB DECK ASSEMBLY D GRY 1 54 08-0065 Membrane, center 4 window
3 ELEV ASSB ELEVATION ASSEMBLY D. GRY 1 55 11-0002 REAR ELEVATION BUSHING 2
56 11-0003 UPRIGHT PIVOT BUSHING 2
5 19-0010 UPRIGHT PIVOT BRACKET 2 57 1
6 19-0013 SAFETY LATCH 1 58 14-0069 END CAP DECAL 2
7 19-0014 MOTOR MOUNTING BRACKET 1 59 14-0145 CONSOLE DECAL 980S 1
8 19-0015 MOTOR COVER BRACKET 6 60 XX-0032 MOTOR COVER DECAL 980S 1
9 19-0029 OPTICAL WHEEL BRACKET 1 62 14-0024 SAFETY LATCH DECAL N/S 1
10 19-0019 BELT GUIDE 2 63 14-0025 WARNING FOLDING DECAL N/S 1
64 14-0026 WARNING CONSOLE DECAL N/S 1
12 19-0032 SPRING ANCHOR BRACKET 2 65 02-0078 MOTOR TENSION SPRING 1
13 06-0018 BASE PAN MOTOR 1 66 02-0002A DECK LIFT SPRING 4
67 02-0004 SCREW, 8X 5/8 PHIL PH 57
68 02-0005 SCREW, 8X 5/8 PHIL PH HILO 8
16 05-0007 SIDE BOARD EXTRUSION 2 69 02-0006 BOLT, 5/16 X 5 - 1/2 SHOULDER BOLT 1
17 06-0027 PIVOT SUPPORT COVER 2 70 02-0007 5/16-18 NYLOCK NUT 4
19 06-0003 PULLEY vx0086 8 GR not shown 1 71 02-0008 SCREW, 5/16-18 X 3/4 HEX 3
21 06-0073 3-PC LCD CENTER Plastic Console 4 wdw 1 72 02-0009 NUT, 5/16-18 WHIZLOC 3
22 06-0080 FAN 5" 8mm bore 1 76 02-0013 LOCK WASHER, 1/4 8
23 06-0020 BASE PAN END 1 77 02-0014 SCREW, 1/4-20 X 2 - 1/2 HEX 10
24 06-0004 BASE PLUG 2 78 02-0015 SPRING WASHER 4
25 06-0005 DOME PLUG 4 79 02-0016 SCREW, 3/8-16 X 2 - 1/2 HEX 1
26 06-0025 MOTOR COVER 1 80 02-0017 NUT, 3/8-16 NYLOCK 2
27 06-0008 END CAP 1 81 02-0018 PUSH NUT, 3/8 HAT 4
82 02-0019 CARRIAGE BOLT 10-24 X 1-1/2 4
29 06-0019 BASE PAN CENTER 1 83 02-0020 SCREW, 1/4-20 X 2-1/2 SOCKET HEAD 2
30 06-0011 2" ROLLER WHEEL 2 84 02-0021 WASHER, 9/32 X 5/8 X 1/8 3
31 06-0012 3” ROLLER WHEEL 2 85 02-0022 NUT, 10-24 NYLOCK 4
32 06-0013 UPRIGHT SPACE 2 87 02-0024 CARRIAGE BOLT 5/16 X 1 2
33 10-0004 RUBBER FOOT 3 88 02-0025 WHEEL AXLE 2
34 10-0002 BOARD ISOLATOR 8 89 02-0026 PUSH NUT 10
35 10-0005 FOAM GRIP 2 91 02-0028 SAFETY KEY 1
36 08-0077 FERRITE CORE 1 93 02-0030 SCREW, 8-32 X 5/8 HEX TRILOBE 1
37 12-0022 ACTUATOR (ELEVATION MOTOR) 1 94 02-0031 SCREW, 3/8-16 X 1 3/4 HEX 1
38 12-0016 DRIVE MOTOR 1
39 03-0003 WALKING BOARD 1
40 04-0008 WALKING BELT 18" X 105" 1 97 02-0034 SCREW, 8-32 X 5/8 PPH N/SHOWN 1
41 04-0004 POLY V BELT 1 98 02-0035 NUT, 8-32 NYLOCK NOT SHOWN 4
42 09-0012 FRONT ROLLER ASSEMBLY 1 99 02-0036 SCREW, GREEN HEAD 8 X 5/8 PPH 2
43 09-0013 REAR ROLLER 1 101 02-0038 HEX WRENCH 3/16 NOT SHOWN 1
44 13-0011 POWER CORD 1 1
45 13-0003 ENCODER HARNESS 1 1
46 14-0155 OVERLAY OPERATION 1 104 14-0027 EMERGENCY STOP DECAL 1
47 14-0156 OVERLAY CUP HOLDER 1 105 06-0014 BUSHING, STRAIN RELIEF 1
48 13-0016 CONTROL PANEL HARNESS 1 107 06-0016 WIRE TIES NOT SHOWN 10
49 13-0007 JUMPER WIRE 6" NOT SHOWN 1 108 06-0021 WIRE CLAMP NOT SHOWN 5
50 07-0027 UPPER LCD ELECTRONICS 1 109 06-0022 RESET GUIDE TUBE NOT SHOWN 1
51 08-0014 MOTOR CONTROLLER 1 110 06-0024 HEX WRENCH CLIP NOT SHOWN 1
52 08-0047 OPTICAL ENCODER 1 111 10-0007 6" CROSS HANDLEBAR FOAM GRIP 2
Parts List - 980S Treadmill
