17
FUNCTION OVERVIEW
TV (CATV/terrestrial) 5...900 MHz
Satellite 900....3100 MHz
FM 87,5...108 MHz
Spectrum analysis 5...3100 MHz
Digital
CATV J83 A/C (DVB-C) 16, 32, 64,
128 ,256 QAM
J83 B
64 QAM
DOCSIS
64, 256 QAM
Analogue
CATV PAL, NICAM
B/G, I, D/K, L/L´, M/N
NTSC, NICAM
B/G, I, D/K, L/L´, M/N
SECAM, NICAM
B/G, I, D/K, L/L´, M/N
Digital-
terrestrial COFDM (DVB-T) 2k, 8k;
4, 16, 64 QAM; 6,7,8 MHz
ATSC
8 VSB
Analogue-
terrestrial PAL, NICAM
B/G, I, D/K, L/L´, M/N
NTSC, NICAM
B/G, I, D/K, L/L´, M/N
SECAM, NICAM
B/G, I, D/K, L/L´, M/N
Digital-
satellite DVB-S(2)
QPSK, 8PSK
Analogue-
satellite PAL
B/G, I, D/K, L/L´, M/N
NTSC
B/G, I, D/K, L/L´, M/N
SECAM
B/G, I, D/K, L/L´, M/N
Radio FM
Spectrum
analyser Level measurement,
Video/audio carrier, Levels
of digital signals, C / N
Frequency measurement,
Frequency spacing
CTB, CSO
Constellation
analyser Constellation,
4,16,32,64,128,256QAM,
COFDM
MER, BER,
Frequency offset
Echo display
(DVB-T)
NICAM-BER BER measurement in analogue TV modulation
Memory oscil-
loscope Audio, Amplitude, Daviati-
on, Frequency
Video, Line memory, Am-
plitude, S/N weighted, S/N
unweighted
DiSEqC TM , Swing in/out,
22 kHz carrier, modulation
MPEG screen SID, PMT, PCR, Channel name, type of service, programme status, CA information,
elementary current, video/audio, NIT
DiSEqC screen DiSEqC TM 2.0
transmitter and receiver
UFO ® micro DiSEqC TM
LNB multimeter current
0...30 V DC
current
0...600 mA DC
Remote feed currrent and
voltage
RECEPTION RANGES
DEMODULATION
MEASUREMENT OPTIONS
SAVING MEASURED VALUES
Internal memory Data logging
Printer
