16
FUNCTION OVERVIEW
Mains
external AC power supply unit
100...240 V
Battery
internal Li-Ion battery
12 V/6,5 AH
external battery supply
vehicle
11 V...16 VDC
keyboard
12 hardkeys
On/Off, Help, Prog.+, Prog.-,
Analyze, Source, OSD/Off, Vol.+,
Vol.-, Copy, Function, Extend
external keyboard
ASCII keyboard (PS2)
to enter ASCII characters
Touch
Infra-red Touch
Intuitive operation and ASCI
character entry
Ethernet
RS232
PCMCIA-Module
analogue modem
GSM modem
Analogue video
TV-CATV
TV terrestrial
Satellite
SCART/video
FTA digital video
DVB-C
J83 B
DVB-T
ATSC
DVB-S
TS-parallel/ASI
Scrambled digital
video
DVB-C
J83 B
CI/CA
DVB-T
ATSC
CI/CA
DVB-S
CI/CA
TS-parallel/ASI
CI/CA
Display
Position
green signal
red signal
operational mode/
standby
Front
(using ON/OFF button)
In mains or external DC
operation
Battery operation
LNB supply
Front
(using EXTEND button)
Voltage supply is on,
blinks if overloading is
greater than 0.6 A
external voltage is con-
nected
Note:
Switch to “standby” by pressing ON/OFF and then selecting the “suspend Mode”, or
by closing the display cover!
Display
Position
green signal
yellow signals
Battery status
rear panel
green = charging
5 x each 20 % = Battery
status
OPERATION
OPERATION
REMOTE CONTROL
VIDEO DISPLAY
SIGNALLING
