KORG Mobile Monitor Amplifier MMA130 - Manual (Page 8)

8
Using a WAVEDRUM stand
You.can.attach.the.basket.section.of.the.Korg.ST-WD.per-
cussion.stand.to.the.MMA130,.and.place.a.Korg.WAVE-
DRUM.on.it.
Caution
Make.sure.that.you.fully.understand.the.following.informa-
tion.before.you.attach.a.WAVEDRUM.to.the.MMA130.
•. Do. not. attach. anything. other. than. the. ST-WD. to. the.
MMA130’s.ST-WD.socket..Doing.so.may.damage.the.
ST-WD. socket,. or. cause. the. system. to. fall. over. and.
cause.injury.
•. Adjust.the.height.so.that.the.highest.point.does.not.ex-
ceed.1.meter.(approximately.3.3.feet).when.the.WAVE-
DRUM.is.placed.on.the.basket.section.of.the.ST-WD..
If.the.height.is.greater.than.1.meter.(approximately.3.3.
feet),.the.system.may.fall.over.and.cause.injury.
•. Attach.the.included.stabilizer.to.the.MMA130.when.us-
ing.the.WAVEDRUM..If.this.part.is.not.attached,.the.
system.may.fall.over.and.cause.injury.
•. Do. not. transport. the. MMA130. with. the. ST-WD. at-
tached,.and.do.not.lift.or.transport.the.system.by.grasp-
ing.the.ST-WD.attached.to.the.MMA130..
.
If.you.do.so,.the.WAVEDRUM.might.fall,.causing.injury.
or.damage.
Attaching the ST-WD
*.You’ll.need.a.Philips.head.screwdriver.(no.2).to.attach.
the.ST-WD.
1. . Remove.the.cap.that.covers.the.ST-WD.socket.
Note:. Take.care.not.to.let.screws.or.other.objects.fall.into.the.
hole..It.may.be.impossible.to.remove.the.object.you.dropped,.
or.the.object.might.damage.components.inside.the.MMA130.
Note:. Leave.the.cap.attached.when.you’re.not.using.the.ST-
WD.
2. . Loosen.the.two.fastening.screws.located.on.the.rear.of.
the.MMA130.so.that.the.ST-WD.can.pass.through.
Cap
Fastening screws
3. . Remove.the.base.from.the.ST-WD,.and.insert.it.all.the.
way.into.the.ST-WD.socket.
Note:. Insert.the.ST-WD.all.the.way.in.until.the.thick.part.with.
the.knob.touches.the.MMA130..If.it.is.not.fully.inserted,.the.
system.may.tip.over.and.cause.injury.
Don’t allow
a gap
4. . Position. the. ST-WD’s. knob. toward. the. rear. of. the.
MMA130,.and.firmly.tighten.both.of.the.MMA130’s.fas-
tening.screws.to.ensure.that.the.ST-WD.is.secure.
5. . Make.sure.that.each.movable.part.of.the.MMA130.is.
firmly. fastened,. and. then. place. the. WAVEDRUM. on.
the.basket..Rotate.the.nut.below.the.basket.to.fasten.
the.WAVEDRUM.so.that.it.cannot.move.
Angle
adjustment knob
Nut
Basket
WAVEDRUM
Handle
Stabilizer
ST-WD
Height
adjustment knob
6. . Adjust.the.height.and.angle.of.the.ST-WD.basket,.and.
firmly.tighten.each.of.the.ST-WD’s.knobs.
Note:. Use.caution.to.make.sure.that.the.WAVEDRUM.does.
not.fall.
Note:. Adjust.the.height.to.1.meter.(approximately.3.3.feet).or.
lower.
1 meter or lower
