FUNCTIONAL DESCRIPTION
CONTROLS AND COMPONENTS:
1. Heat Gun
2. Stand
3. Air Reduction Nozzle
4. Scraper Nozzle
5. Deflector Nozzle
6. Angle Nozzle
7. Scraper Handle
8. Scraper Blades
ASSEMBLY
This heat gun comes with four different nozzles and a scraping tool with specially
shaped blades. Change blades or nozzles when necessary to make your job easier.
THIS SET INCLUDES:
• Air Reduction Nozzle
• Deflector Nozzle
• Scraping Tool
• Scraper Nozzle
• Angle Nozzle
with Interchangeable
Blades
9
10
SYMBOLS
IMPORTANT: Some of the following symbols may be used on your tool. Please
study them and learn their meaning. Proper interpretation of these symbols will
allow you to operate the tool better and safer.
SYMBOL
NAME
EXPLANATION
V
Volts
Voltage (Potential)
A
Amperes
Current
Hz
Hertz
Frequency (Cycles per Second)
W
Watt
Power
Kg
Kilograms
Weight
Alternating Current
Type of Current
Direct Current
Type of Current
Alternating or Direct Current
Type of Current
Earthing Terminal
Grounding Terminal
Class II Construction
Denotes Double Insulation
min
Minutes
Time
s
Seconds
Time
Diameter
Size of Drill Bits,
Grinding Wheels, etc.
No load speed
No-load Rotational Speed
.../min
Revolutions per Minute
Revolutions, Surface Speed,
Strokes, etc. per Minute
1,2,3, …
Ring Selector Settings
Speed, Torque or Position Settings
4
8
2
3
5
6
1
7
