— 33 —
R
L
Installing Radio Bracket in Japanese-made Cars (J-Cars)
■
8mm
5mm
5mm
8mm
(For Nissan Car)
After aligning the J-Car bracket with the
factory-installed radio bracket, tighten the
screws.
Accessory6
for Toyota car
Accessory5
for Nissan car
Factory trim bezel
Accessory8
J-Car Bracket
(follow indications for L/R)
Accessory9
J-Car Trim Plate
(place thick part on
bottom)
Factory-installed
Radio Bracket
Factory-installed
Radio Bracket
Installation (Japanese-cars)
(For Toyota Car)
After aligning the factory-installed radio
bracket, tighten the screws.
A J-Car Bracket (Accessory 8 ) is not
used when fitting in a Toyota car.
Damage to the unit will result from
using screws other than those provided.
2CAUTION
NOTE
