5
USING THE ACCESSORIES
The Vario spray wand allows you to adjust the cleaning pressure. To clean at maximum pres-
sure, the Vario wand must be positioned to the high pressure setting (+). To apply detergent,
the wand must be positioned to the low pressure setting (-).
For high pressure turn
wand collar in the plus
(+) direction.
For low pressure turn
wand collar in the
minus (-) direction.
WARNING TO AVOID SERIOUS INJURY, NEVER POINT SPRAY
NOZZLE AT YOURSELF, OTHER PERSONS OR ANIMALS
Vario spray wand
ASSEMBLE THE GUN
Step 1
Install spray wand into trigger gun. Push in and turn cockwise to lock spray wand in
place. Turn the wand collar clockwise onto the spray wand threads.
wand collar
Step 2
Attach high pressure hose
to trigger gun.
Step 1
Insert the Vario spray wand into the gun
Push in and turn clockwise to lock spray wand in place.
Step 2
Attach high pressure hose to trigger gun.
