NOTE: Engines controls shown may appear different.
Item Description
1. Water inlet
2. Detergent suction tube
3. Oil fill cap
4. Knob Assembly (two each):
Hex Head Screw
Serrated Washer Knob
5. High pressure hose
6. Detergent filter
7. Handle
8. Trigger gun safety lock
9. Trigger gun
10. Pull start
11. Gas tank
12. Vario spray wand
13. High pressure outlet
(not pictured)
14. Manual
15. Detergent tray
1
NEVER!
MODEL K 1800 AB / K2300 ABI OVERVIEW
Never point nozzle at people or animals.
Never drink alcohol or use drugs while operating this equipment.
Never spray electrical connections, electrical outlets or fixtures.
Never add fuel with the engine running or operate where fuel has been spilled.
Never touch hot surfaces or allow accessories to contact hot surfaces.
Never operate in an enclosed space, exhaust fumes are dangerous.
Never operate near utilities with open flames.
Never operate without the water turned on and never use hot water.
