Figure 2 The KCT Back Panel
Inputs
17 B-1 and B-2 Left and Right
Balanced Inputs
18 S-1, S-2, and S-3 Left and
Right Single-ended Inputs
19
T
ape Left and Right Inputs
20 C-1 and C-2 Left and Right
CAST
Inputs
T
ape Output
21 T
ape
Output
Main (Zone) Outputs
22 Preamp Left and Right Outputs
23 CAST
Preamp Outputs
Zone 2 Outputs
24 Balanced Left and Right Outputs
25 Single-ended Left and Right
Outputs
Back Panel Remote
Control
Inputs and Outputs
26 Krell Link In and Out
27 12 VDC In and Out
28 RC-5 In
29 RS-232
Phono Stage Connector
30 Phono Power
Power
31 IEC Power Connector
