ENGLISH
55
TECHNICAL SPECIFICATIONS - CHASSIS 250/300 XC/XC-W/EXC-E/EXC-E SIX DAYS 2008
»
STANDARD ADJUSTMENT – FORK
250/300 XC-W/EXC/EXC-E 250/300 EXC-E EXC-E SIX DAYS 250/300 XC
WP 4860 MXMA PA WP 4860 MXMA PA WP 4860 MXMA CC
14.18.7D.04
14.18.7D.34 14.18.7D.28
Compression adjuster 22 clicks 24 clicks 20 clicks
Rebound adjuster 20 clicks 22 clicks 21 clicks
Spring 432.505.00.042W 432.505.00.044W 432.455.00.044W
Preload Adjuster 2 turns 2 turns –
Air chamber length 110 mm 110 mm –
Fork oil SAE 5 SAE 5 SAE 5
STANDARD ADJUSTMENT – SHOCK ABSORBER
250/300 XC-W/EXC/EXC-E 250/300 EXC-E EXC-E SIX DAYS 250/300 XC
Typ WP 5018 PDS DCC WP 5018 PDS DCC WP 5018 PDS DCC
12.18.7D.04
12.18.7D.34 12.18.7D.28
Compression adjuster
Low speed
15 clicks 15 clicks 15 clicks
High speed 1,5 turn 1,5 turn 1 turn
Rebound adjuster 24 clicks 24 clicks 23 clicks
Spring 69-250 69-250 66-250
Spring preload 7 mm 8 mm 5 mm
Static sag 35 mm ± 2 mm 35 mm ± 2 mm 33 mm ± 2 mm
Riding sag 105 mm ± 5 mm 105 mm ± 5 mm 112 mm ± 5 mm
TIGHTENING TORQUES – CHASSIS
Collar screw, front wheel spindle
M24x1,5 40 Nm
Brake caliper, front M8 (10.9) Loctite 243 + 25 Nm
Brake disks M6 (10.9) 14 Nm
Screw steering head M20x1,5 10 Nm
Lower Screw steering head M20x1,5 Loctite 243 + 60 Nm
Clamping screws, upper fork bridge (machined fork bridge) M8 (10.9) 17 Nm
Clamping screws, lower fork bridge (machined fork bridge) M8 (10.9) 12 Nm
Clamping screws, upper steering stem M8 (10.9) Loctite 243 + 17 Nm
Clamping screws, upper fork bridge (forged fork bridge) M8 (10.9) 20 Nm
Clamping screws, lower fork bridge (forged fork bridge) M8 (10.9) 15 Nm
Clamping screws, fork stubs M8 (10.9) 15 Nm
Collar nut, rear wheel spindle M20x1,5 80 Nm
Hexagon nut, swing arm bolt M16x1,5 100 Nm
Hexagon collar screw, handlebar clamp M8 (10.9) 20 Nm
Allan head screw, handlebar support M10 (10.9) Loctite 243 + 40 Nm
Shock absorber, top M12 (10.9) Loctite 243 + 80 Nm
Shock absorber, bottom M12 (10.9) Loctite 243 + 80 Nm
Flat-head screws for subframe M8 (10.9) Loctite 243 + 35 Nm
Collared nuts for rear sprocket screws M8 (10.9) Loctite 243 + 35 Nm
Flat-head screw for side stand M8 (10.9) Loctite 243 + 40 Nm
Ball joint for push rod M6 (10.9) 10 Nm
Engine mounting bolt M10 (10.9) 60 Nm
Engine brace M8 (10.9) 33 Nm
Screw adjusting ring spring preload shock absorber M6 8 Nm
Spoke nipple M4,5 / M5 5 Nm
Other screws on chassis M6 10 Nm
M8 25 Nm
M10 45 Nm
Other collar nuts on chassis M6 15 Nm
M8 30 Nm
M10 50 Nm
