Rebound damping of shock absorber
By using the adjusting screw [4], the degree of damping of the rebound can
be adjusted. Turn the knob to the right side to increase damping, turn it to
the left side to reduce damping during rebounding.
STANDARD ADJUSTMENT:
– Turn the adjusting screw clockwise to the stop.
– Then turn the adjusting screw counterclockwise, counting the number of
clicks that corresponds to the respective type of shock absorber.
Typ WP Suspension 12187D02 . . . . .24 clicks
Typ WP Suspension 12187D04 . . . . .24 clicks
Typ WP Suspension 12187D27 . . . . .23 clicks
Typ WP Suspension 12187D28 . . . . .23 clicks
Typ WP Suspension 12187D33 . . . . .24 clicks
Typ WP Suspension 12187D34 . . . . .22 clicks
The damping unit of the shock absorber is filled with high-compression nitro-
gen. Never try to take the shock absorber apart or to do any maintenance work
yourself. Severe injuries could be the result.
Never unscrew the black screw [5] connection (15mm).
Compression damping of shock absorber
The low-speed and high-speed compression damping can be adjusted sepa-
rately on the shock absorber (Dual Compression Control).
Low and high speed refers to the movement of the shock absorber during com-
pression and not to the speed of the motorcycle.
The low and high-speed technology overlaps.
The low-speed setting is primarily for slow to normal shock absorber
compression rates.The high-speed setting is effective at fast compression rates.
Turning in a clockwise direction will increase the damping, turning counter-
clockwise will decrease the damping.
STANDARD LOW-SPEED SETTING:
– Turn the adjusting screw [1] to the limit in a clockwise direction using a
screwdriver .
– Unscrew the respective number of clicks for the specific type of shock
absorber in a counterclockwise direction.
Typ WP Suspension 12187D02 . . . . .15 clicks
Typ WP Suspension 12187D04 . . . . .15 clicks
Typ WP Suspension 12187D27 . . . . .15 clicks
Typ WP Suspension 12187D28 . . . . .15 clicks
Typ WP Suspension 12187D33 . . . . .13 clicks
Typ WP Suspension 12187D34 . . . . .15 clicks
The damping unit of the shock absorber is filled with high-compression nitro-
gen. Never try to take the shock absorber apart or to do any maintenance work
yourself. Severe injuries could be the result.
Never unscrew the black screw [2] connection (24mm).
STANDARD HIGH-SPEED SETTING:
– Turn the adjusting screw [3] to the limit in a counterclockwise direction
using a box wrench.
– Unscrew the respective number of turns for the specific type of shock absorber
in a clockwise direction.
Typ WP Suspension 12187D02 . . . . .1,5 turn
Typ WP Suspension 12187D04 . . . . .1,5 turn
Typ WP Suspension 12187D27 . . . . .1 turn
Typ WP Suspension 12187D28 . . . . .1 turn
Typ WP Suspension 12187D33 . . . . .1,75 turn
Typ WP Suspension 12187D34 . . . . .1,5 turn
