14
PARTS LIST
MODEL NO: IN2730SF
NO. DESCRIPTION MODEL/SIZE PART NO.
1 Hood Casing SY-027-3-001
2 Hood Casing Support SY-027-5-002
3 Bottom Casing Support SY-027-3-002
4 Bottom Casing SY-027-5-003
5 Blower Cover SY-027-3-004
6 Left Locknut SY-027-5-051
7 Left Squirrel Cage SY-027-5-052
8 Air Chamber SY-027-5-053
9 Halogen Light Housing SY-027-3-003
10 Aluminum Filters SY-027-3-005
11 Right Locknut SY-027-5-056
12 Right Squirrel Cage SY-027-5-055
13 Motor SY-027-5-054
14 Indicator Sensor SY-027-3-006
15 ISC SY-027-5-058
16 Control Unit SY-027-3-008
17 Processor Board SY-027-5-074
18 Transformer SY-027-5-075
19 Electronic Support Panel SY-027-5-016
20 Processor Board Box SY-027-5-031
21 Capacitor SY-027-5-057
22 Exhaust Connector SY-027-5-007
23 Wiring Box SY-027-5-009
Optional Liner
Model No.
24 Liner INL36211A
