Kobe Range Hoods CH7742SQ User Manual
Page 15
14
- SPECIFICATION -
STYLE
CH-177 MODELS
Size
30”
36”
42”
48”
Dimension (WxDxH)
30” x 22” x 9” 36” x 22” x 9” 42” x 22” x 9” 48” x 22” x 9”
Net Weight (lbs)
48.5
50.6
52.8
55
Features:
Stainless Steel #304
●
●
●
●
Fan Type
Turbine
Impeller
Turbine
Impeller
Turbine
Impeller
Turbine
Impeller
Control Button
6
6
6
6
Halogen Light (12 Volts)
20W x 2
20W x 2
20W x 3
20W x 3
Duct Free*
●
●
●
●
Safety Screen
2
2
2
2
Oil Container
4
4
4
4
Accessories:
(Additional Purchase)
Back panel
●
●
●
●
6” Round Charcoal Filter
●
●
●
●
Multi Duct Exhaust:
6” Round (Top)
●
●
●
●
7” Round (Top)
●
●
●
●
3¼” x 10” (Top)
●
●
●
●
3¼” x 10” (Rear)
●
●
●
●
*When used with optional 6” round charcoal filter.
CH-177 Models
Performance
QuietMode
Low
Medium
High
CFM
1
500
640
720
800
Sone
2
1
2.8
4.5
4.8
R.P.M.
850
1,100
1,350
1,600
Power Consumption
127W
154W
168W
205W
Ampere
1.2
1.5
1.6
2
1
SP:Ø
2
1 Sone is equivalent to sound of a refrigerator at 40 decibels.
