- PARTS LIST -
1 Plastic Multi Duct Exhaust Attachment 22 Light Transformer Support Screw
2 Plastic Vent Cover 23 Light Transformer Support
3 Plastic Rear Vent Cover 24 Transformer
4 Plastic Vent Cover Screw 25 Control Support Screw
5 Rear Plastic Vent Cover Frame 26 Control Support
6 Hood Casing 27 Control Panel
7 Motor Chamber 28 Control Board
8 Motor 29 Capacitor
9 Turbine Impeller 30 Processor Board Box
10 Oil Tunnel Ring 31 Processor Board
11 Oil Tunnel 32 Round Head Screw (TS 3” x 15”)
12 Bottom Casing 33 Light Transformer
13 Rear Oil Container 34 Motor Position Screw
14 Impeller Safety Screen 35 Round Head Screw (TS 4” x 12”)
15 Oil Container for Safety Screen 36 Bottom Casing Screw (3/16” x ¾”)
16 Power Cord 37 Impeller Plastic Cover
17 Flat Head Screw (3/16” x ¾”) 38 Impeller Safety Screen Screw (3/16” x ¾”)
18 Power Cord Frame
19 Round Head Screw (3/16” x 3/8”)
20 Round Head Screw (TS 4” x 12”)
21 Halogen Light
