Page 9
8
# PART
QTY
#
PART
QTY
1
MAIN FRAME
1
36
HEX HEAD SCREW 3/8"*26
1
2
BALL BEARING HOUSING
2
37
WASHER
2
3
BALL BEARING
2
38
IDLER WHEEL PLATE
1
4
INSIDE BEARING COLLAR
1
39
NYLOCK NUT 3/8"
1
5
BIG WASHER
1
40
SPACER OF IDLER WHEEL
1
6
BC NUT
1
41
IDLER WHEEL
1
7
OUTSIDE BEARING COLLAR
1
42
NYLOCK NUT 3/8"
1
8
CURVE WASHER
1
43
HANDLEBA PULSE
1
9
CRANK 1/2"
2
44
BELLOW
1
10 MAGNET
1
45
SENSOR WIRE
1
11 BELT J6*440
1
46
SCREW M4*8
1
12 PULLEY 270MM
1
47
KNOB
1
13 PEDAL (R)
1
48
BUSHING
1
14 PEDAL (L)
1
49
UPRIGHT SEAT TUBE
1
15 REAR STABILIZER
1
50
NYLOCK NUT M8
3
16 END CAP
2
51
WASHER
3
17
SCREW M8*70
4
52
SEAT
1
18 NYLOCK NUT M8
4
53
SCREW M8
1
19 ARC WASHER
12
54
EXTENSION WIRE
1
20 FRONT STABILIZER CAP
2
55
SCREW M8*15
8
21 FRONT STABILIZER 1
56
UPRIGHT TUBE
1
22 SCREW 3/8"
1
57
SCREW
1
23 WASHER 1
58
TENSION
KNOB
1
24 BC NUT 3/8"
1
59
LOW TENSION WIRE
1
25 SPACER OF FLY WHEEL
1
60
COMPUTER SCREW
4
26 BEARING
3
61
COMPUTER
1
27 FLY WHEEL
1
62
HANDLEBAR TUBE
1
28 AXLE OF FLY WHEEL
1
63
FOAM GRIP
2
29 GREASED WHEEL
1
64
HANDLEBAR TUBE CAP
2
30 WASHER 1
65
SCREW
M4*11
4
31 NYLOCK NUT M8
2
66
SCREW M5*75
5
32 HEX HEAD SCREW M8*60
2
67
COVER (L)
1
33 ARC MAGNETIC PLATE
1
68
COVER (R)
1
34 ARC MAGNET SPRING
1
35 SPRING OF IDLER WHEEL
1
DCV 5.2U PARTS LIST
