KTM 525 EXC 2006 - Manual (Page 19)

525 EXC 2006
FIG PART NUMBER DESCRIPTION QTY
1 59036030000 INTAKE VALVE D=35MM 2
2 59036031000 EXHAUST VALVE D=30MM 2
3 59036027000 VALVE-STEM SEALING RACING 4
6 59036028244 VALVE SPRING KIT (1X)RAC. 2001 4
9 59036033000 VALVE COLLET KK 6 H 8
10 59036062000 ADJUSTMENT SCREW M6X0,75 4
11 59036062100 NUT M6X0,75 4
13 59036056000 ROCKER ARM SHAFT INTAKE 1
14 59036057000 ROCKER ARM SHAFT EXHAUST 1
15 59036061095 END CAP ROCKER ARM SHAFT 2
16 0770191016 O-RING 19,10X1,60 NBR 70 2
17 59036060010 SHIM ALU 5,2X10X2 2
18 0912050083 AH SCREW DIN 912 M 5X8 2
19 59036050000 DECOMPRESSION SHAFT CPL. 1
20 0770051016 O-RING 5,10X1,60 NBR 70 1
22 59036059000 DECOMPRESSION LEVER SPRING 1
23 0471080000 CIRCLIP DIN0471- 8X0,8 1
30 59036060144 ROCKER ARM INTAKE CPL. 1
31 59036061144 ROCKER ARM EXHAUST CPL. 1
05590363 / C065903601 * NEW PART X AS REQUIRED
17
VALVE DRIVE
