65 SX 2007
FIG PART NUMBER DESCRIPTION QTY
1* 4610300120030 FRAME 65 SX "MD6R" bl. 2007 1
2 46103002044 SUB FRAME 65 SX 2002 1
3 58711054050 METAMOLL FOR BATTERY BRACKET 2
4 54606004000 PLUG 37MM 2
5 0017060203 EJOT PT SCREW K60X20 WS=6 2
7 0934080003 HEXAGON NUT DIN0934-M 8 4
8 54610052000 SPROCKET SCREW-AH M8X20 WS=6 2
9 54510052100 SPROCKET SCREW-AH M8X26 WS=6 2
11 0125080003 WASHER DIN0125-A 8,4 2
12 54310086200 SELF LOCKING NUT M8 10.9 2
13 59001037000 SPECIAL SCREW M8X26 WS=10 2
15 0931080805 HH SCREW DIN 931 M8X80 10.9 2
20 50203053000 CHAIN ROLL D=30MM 1
21 74003021000 BUSHING 8.2 X 12 X 6 1
22 0625006087 GROOVED BALL BEAR. 608 2RS C3 2
23 36003014000 LOCK WASHER 8MM 2
25 0015080303 HH COLLAR SCREW M 8X30 WS=10 1
27* 4610304013390A FOOTREST L.+R. CPL. 65 SX 03 x
28 54803044000 BOLT FOR FOOT PED 03 2
29 54603041000 FOOTREST SPRING L/S & R/S 2
30 0125100003 WASHER DIN0125-A10,5 2
31 0094032253 PIN DIN0094-3,2X25 STEEL 2
32 5460304010090 FOOT PED L/S SILVER '98 1
33* 59003041050 FOOT PED R/S EXC SILVER 2000 1
40 50303002182 PLUG-IN CAP SW14 99 2
074610300 / C074610300 * NEW PART X AS REQUIRED
7
FRAME, SUB FRAME
