EC1350C/EC3350HR- Parts List
Page 19
PART #
DESCRIPTION
QTY PART #
DESCRIPTION
QTY PART #
DESCRIPTION
02-0004
SCREW-8x5/8 PHIL PH AB BLACK
24
06-0022
GUIDE-RESET TUBE
1
17-0042
RECT 1x3x16GAx25 7/16
02-0005
SCREW-8x5/8 PPH HILO BLACK TPB
8
06-0024
CLIP-ALLEN WRENCH
2
17-0055
RECT-1x2x16GAx153 1/4"
02-0006
BOLT-HEX 5/16-18x5 1/ GRADE 5-ZP
1
06-0039
WHEEL-KEYS SERIES-2.5"
2
17-0061
RECT 1 1/2x4x16Ax42 3/4"
02-0007
NUT 5/16-18 NYLOCKZP
5
06-0080
FAN 5"X8mm BORE SCREW ON
2
18-0006
SPRING-MOTOR TENSION-PRESET
02-0008
BOLT-CARRIAGE 5/16-18x3/4"GRADE 2-ZP
3
06-0088
SLEEVE-MOTOR TENSION 1/4"
2
18-0008
ROD 3/8x1 1/2"
02-0009
NUT-HEX 5/16 WIZ-FL-LK-ZP
3
06-0084
BAG-PLASTIC 12x12 3MIL-INST PACKET
1
19-0003
BRK-FRONT ROLLER
02-0013
WASHER LOCK 1/4"
8
06-0117
SWITCH HOUSING ROUND GRAY
2
19-0004
BRKT-REAR ROLLER
02-0014
BOLT-HEX 1/4-20x2 1/2" GRADE 5 ZP
9
06-0130
PULLEY MOLDED PLASTIC 1/9"
1
19-0007
BRKT-MOTOR TENSON
02-0015
WASHER-SPRING
2
06-0131
COVER FOR MOTOR-NON SES-VO
1
19-0012
BRKT-CONSOLE MOUNTING
02-0016
BOLT-HEX 3/8-16x2 1/2" GRADE 5
1
06-0132
PAN BOTTOM CONV VO
1
19-0015
BRACKET-MOTOR COVER
02-0017
NUT-NYLOCK HEX 3/8-16
2
07-0030
ELECTRONICS LED-5WIN-HRC
1
19-0019
GUIDE BELT GLAVANIZED
02-0018
NUT-PUSH 3/8 HAT BLACK 375012
2
08-0004
BREAKER-CIRCIT-15AMP
1
19-0023
BRKT-UNIVERSAL
02-0020
SCREW-SHSC 1/4-20x2 1/2"
2
08-0027
SWITCH-REMOTE-W/HARNESS
2
19-0073
BRKT-ELEVATION PIVOT
02-0021
WASHER 9/32 5/8 1/8THICK ZP
2
08-0047
ENCODER-OPTICAL-ALEPH
1
19-0074
BRKT-ACTUATOR MOUNTING
02-0022
NUT-NYLOCK HEX 10-24
4
08-0050
CONTROLLER-REPLACES 08-0013
2
19-0076
BRKT-CONTROLLER
02-0024
CARRIAGE BOLT 5/16x1 GRADE 5 ZP
4
08-0077
CORE-ERRITE
1
19-0077
BRACE-CNTROLLER FRONT ELEVATION
02-0026
NUT-PUSH PZ 001996
1
09-0012
ROLLER-FRONT-20MM SHAFT
1
19-0079
BRKT-BELT GUIDE
02-0027
NUT-T HF 14209H-DB
8
09-0013
ROLLER-REAR-20MM SHAFT
1
19-0097
BRKT-ENCODER-McMILLAN
02-0028
SWITCH-MAGETIC KILL-YIHAN
1
10-0006
TIP-CRUTCH 1" CNV
2
19-0105
BRKT-REAR LEG COVER
02-0030
SCREW-HEX TRILOBE 8-32x1/2"
1
10-0020
GRIP MOLDED ROUND
2
19-0106
BRK-LOWER ELEV GUSSET
02-0031
BOLT-HEX 3/8-16x1 3/4" GRADE 5ZP
1
10-0024
TAPE-ADHEVISIVE 1'X108ft ST567
1
19-0134
BRKT-MORTO MOUNT
02-0033
WASHER-10# EXTERNAL STAR
1
10-0028
ISOLATOR BOARD 3/4"W/LG STUD
8
19-0143
BRKT LEFT STRAIGHT U/R
02-0036
SCREW-PPH 8x5/8 GREEN HEAD
1
11-0002
BUSHING-REAR ELEVAION
2
19-0144
BRKT RIGHT STRAIGHT U/R
02-0038
WRENCH-ALLEN 3/16 SHAFT ARM
1
11-0014
SPACER STEEL TUBE 1.343"
2
19-0147
BRKT FRONT ELEV-REWORK 19-0075
02-0040
RETAINER-GUIDE TUBE
1
11-0016
FYWHEEL 10MPH MCM
1
19-0159
BRKT MTOR SUPPORT REVISED 19-0005
02-0042
SCREW#8x5/8' SD BLACK
2
12-0022
ACTUATOR 400 LB-MAYTECK
1
19-0187
BRKT FRONT ELEV REVISED
02-0050
NUT-NYLOCK HEX 1/4-20
4
12-0023
MOTOR-MC#2917-10MPH-8MM SHAFT
1
20-0063
PROC-PUNCHED FRAMES LONGER17-0055
02-0053 SCREW-SHCS
1/4-20x3/4"
2
13-0003
HARNESS-ENCODER
1
20-0083
PROC RT U/R 17-00671
02-0054
SCREW-HWH MACH 8-32x3/8"LT HAND
1
13-0007
WIRE-BREAKER 6"
1
20-0084
PROC LT U/R 17-0061
02-0068
WASHER-FLAT SAE 5/16
2
13-0011
CORD-POWER-90"
1
20-0111
PROC H-BAR 17-0035
02-0082
SCREW-BUTTN HEAD 5/16-18x2 1/2'
2
13-0040
HARNESS CONTROL PANEL +6"
1
21-0001
FRAME BRACE-PUNCHED
06-0001
CONSOLE-LED
1
14-0019
OVERLAY CONSOLE LED-EC2500-GRY/TEAL/RE
1
21-0017
ACTUATOR X-TB-CORNERS CLIPPED(17-0031)
02-0092
SCREW-PHTR #8x3/4" AB BLACK
4
14-0026
DECAL-WARNING CONSOLE-ALL GRAY
1
21-0020
STIFFNER FOR CURVED U/R NOTCHED
02-0099
WASHER -SFW 3/8X7/8X1/8" THICK
1
14-0027
DECAL-EMERGENCY STOP-RED
1
22-0016
ACTUATOR X-TB SUB-ASSEMBLY
02-0103
BOLT-CARRIAGE 10-24x3/4"
4
14-0171
STICKER-MOTOR HR 2.0
1
22-0036
EXTENDED DECK FRAM ASSEMBLY 4"
02-0105
INDRTY-5/16-18 HEAVY WAL AVK
2
14-0028
DECAL CIRCIT BREAKER ALL
1
22-0036
EXTENDED DECK FRAME ASSEMBLY 4"
02-0113
SCREW-HWH SLOTED 8-18x3/4" AB ZP
1
14-0201
DECAL-CAUTION-OPER INST
1
22-0063
U/R SUB-ASSM
02-0123
WASHER-FENDER 1/4x1"
1
14-0204
DECAL CAUTION OPER INST
1
23-0050
FRONT ELEVATION ASSEMBLY
02-0125
SCREW-5/16-18x3/4"BUTTON HD BLACK
2
14-0205
DECAL DISCONNECT-MOTOR COVER
1
23-0067
EXTENDED DECK FRAME&REAR LEG ASSEM
02-0133
NUT RIV 5/16-18 AVKALS4-518-150
2
14-0321
DECAL-10YR MOTOR WARRANTY
1
23-0086
U/R ASSM W/STIFFNER TUBE
02-0137
PLUG PUSH-IN
2
14-0351
DECAL SPEED SERIGRAPH
1
24-0108
CONSOLE ASSEMBY-EC2500/EC1350C
03-0012
WLKBOARD KORETRON 4"LONGER W/OUT
1
14-0352
DECAL INCLINE SERIGRAPH
1
26-0099
INST PACKET EC1350C
04-0004
BELT-POLY V-190J8
1
04-0012
WALKBELT-18"x113"-P33 1 PLY
1
14-0369
DECAL MTR COVER EC1350C
1
05-0011
EXTRUSION-END CAP JOINT
1
15-0028
DIAGRAM-WIRING-McMILLAN
1
05-0019
EXTRUSINS-RT SIDE BRD-DLX LONGER
1
15-0115
INST MANUAL EC 1350C/EC3350C
1
05-0020
EXTRUSION-LT SIDE BRD-DLS-LONGER
1
17-0003
RECT 1x1x18GAx22.44
1
06-0008
ENDCAP 1
17-0030
RECT
1x1x18GAx3
PUNCHED
2
06-0014
BUSHING-STRAIN RELIEF #1237
1
17-0031
RECT 1x2x14GAx22 7/16
1
06-0016
TIES-WIRE
1
17-0032
RECT 1x2x14GAx211/2
1
06-0021
CLAMP WIRE 3367 7/16
1
17-0035
RND 1 1/2x16GAx42 3/4"
2
