Kobe Range Hoods CH0136SQB User Manual

Page 18

Cleaning Stainless Oil Tunnel, Baffle Filters and Spacers

CAUTION

: DRAIN OIL BEFORE RESIDUE CAN OVERFLOW.

1. Remove the baffle filter (reverse the order of baffle installation).
2. Carefully remove oil tunnel.
3. Discard oil and residue.
4. Wash oil tunnel, baffle filters and spacers with warm soapy water.
5. Dry thoroughly and put back.

NOTE: Oil Tunnel, baffle filters and spacers are top rack dishwasher safe.

Replacing Light Bulb

CAUTION

HALOGEN LIGHT UNIT MAY BE HOT! WAIT UNTIL UNIT IS COOL.

1. Make sure all controls are OFF, and range hood is unplugged.
2. Place a flat-head screwdriver into space between the light cover and light housing .
3. Gently remove light cover from housing .
4. Gently pull out the defective light bulb

and discard. Light bulb should be 12V 20W

maximum.

5. Wear a glove or use a cloth to hold new light bulb and push gently but securely into light

socket. NOTE: DO NOT PUSH TOO HARD OR YOU MAY BREAK THE BULB
CONNECTOR.

6. Put back light cover .
7. Plug back power cord and turn on range hood to test for operation.

This manual is related to the following products:

CH0148SQB CH0142SQB
