15
PARTS LIST
MODEL NO.: IS2436GSB
IS2442GSB
(Box 1 of 2)
(Box 2 of 2)
MODEL NO. IS2436GSB
MODEL NO. IS2442GSB
NO. DESCRIPTION MODEL PART NO.
01 Glass Canopy IS2436GSB GC-0036-01
IS2442GSB GC-0042-01
02 Housing Connector PH-0001-01
03 Sensor Control PH-0002-01
04 Light Support Panel (Top) PH-0003-01
05 Light Support Panel (Bottom) PH-0003-02
06 Halogen Light PH-0004-01
07 Hood Casing PH-0005-01
08 LCD Screen PH-0006-01
09 Baffle Filter BF-0124 PH-0007-01
MODEL NO. IS124DC
NO. DESCRIPTION MODEL PART NO.
10 Inner Duct Cover PD-0001-01
11 7” Round Damper PD-0002-01
12 Rubber Seal PD-0002-02
13 Outer Duct Cover PD-0001-02
14 Telescopic Stack PD-0001-03
15 Transformer Box PD-0001-04
16 Transformer PD-0003-02
17 Motor Housing PD-0003-05
18 Air Chamber PD-0003-06
19 Air Flow Grill PD-0003-11
20 Blower Cover PD-0003-10
21 Locknut PD-0003-09
22 Squirrel Cage PD-0003-08
23 Power Board Box PD-0003-01
24 Capacitor PD-0003-04
25 Power Board PD-0003-03
26 Motor PD-0003-07
27 Power Board Box Cover PD-0003-12
RECIRCULATING KIT – ITEM NO. RD-0124 (OPTIONAL)
NO. DESCRIPTION MODEL PART NO.
28 Box RD-0004-03
29 Box Bracket RD-0004-02
30 ST3X10 RD-0004-01
31 ST3X10 RD-0004-01
32 7” Round Adapter RD-0005-01
33 Grease Filter RD-0007-01
