- 4 -
DVD PLAYER KH6515/6516
1. Technical Data
Power supply: AC 220 V - 240 V ~50 Hz
Power consumption: 15 Watt
Power consumption:
Standby:
0,7 W
TV standard: PAL/NTSC
Operating temperature: +5 ~ +35°C
Humidity: 5 ~ 90% (no condensation)
Dimensions
(L x D x H):
241 x 430 x 50 mm
Weight : 2,1 kg approx.
Video Output
Output level: 1 + 0.2/-0.2 Vp-p (75 Ω)
Horizontal resolution: > = 500 Lines
Signal-to-noise ratio: 60 dB
Audio Output
Impedance: 10 kΩ
Output level: 1.8 + 0.2/-0.8 Vrms (1kHz, 0dB)
Harmonic distortion: 0.01 % (JIS-A 1kHz, typical)
Dynamic range: 80 dB (JIS-A 1 KHz, typical)
Signal-to-noise ratio: 95 dB (JIS-A 1 kHz, typical)
Digital audio output
Coaxial output and optical output
USB slot
Readable
USB memory sticks:
USB1.1 and 2.0 up to 512 MB
Memory card slot
Readable memory cards: CFI/CFII (512 MB), SD (512 MB), MS/MSPro
(128 MB), MMC (128 MB), SM (128 MB)
2. Applications and functions
The SilverCrest KH 6515/ KH6516 DVD player is intended exclusively for
stationary use in enclosed spaces. The device is intended exclusively for pri-
vate, non-commercial use.
This device is intended for use as an electronic entertainment device for the
playback …
•
...of DVD videos in 12 cm and 8 cm (diameter) formats with Country/
Regional code 2 or
, designated by the Logo .
• ...of the video formats MPEG-4/MPEG-4 ASP and with DivX 3.11, DivX
4.x, DivX 5.x, DivX 6, multichannel DivX and DivX Pro as well as Nero
Digital compressed videos.
• ... of video-CDs (VCDs) and Super video-CDs (S-VCDs) in 12 cm and
8 cm (diameter) formats, designated by the Logo
.
• ... of audio-CDs in 12 cm and 8 cm (diameter) formats, designated by
the Logo
.
• ... generally of the data format CD Audio (.cda), MP3 (.mp3), Windows
Media Audio (.wma), DivX (.avi), Nero Digital (.mp4) und JPEG (.jpg)
on the storage media CD-R, CD-RW, USB memory sticks as well as
Memory Cards of the type CF I, CF II, SD, MS, MSPro, MMC und SM.
You can connect to the Silvercrest KH 6515/ KH 6516 DVD player for image
outputs during playback of DVDs, VCDs, S-VCDs, Audio CDs and the MP3
data formats, Windows Media Audio and JPEG
•
Stereo and Mono televisions with the formats PAL or NTSC and the picture
formats 4:3/16:9.
• LCD/Plasma picture screens or video-projectors, if for this the corresponding
connection potential is available and the connection of a DVD player is
provided for/allowed by the manufacturer of the playback device
You can connect to the Silvercrest KH 6515/KH 6516 DVD player for sound
output, for example music…
•
from the speaker of one of the televisions connected to the DVD player
• from external audio components such as a HiFi system, receiver or
surround sound system (analogue/digital)
Attention!
No liability/warranty will be assumed for damage resulting from improper
use of the device!
3. Delivery Contents
- DVD-Player
- Infrared remote control
- 2 Batteries for remote control, type AAA/ (Micro cells)
- RGB Scart cable
- Audio/Video RCA cable
- Nero Digital CD
- Operating manual
4. Operating elements
A. DVD player front panel
q
/ PLAY/PAUSE button
w STOP button
e SKIP BACKWARDS button
r SKIP FORWARDS button
t F.RWD button
y F.FWD button
u Memory card slot for SD/MMC/MS/MSPro and MS cards
(behind the front cover)
i Memory card slot for compact flash memory cards (CF I/ CF II)
(behind the front cover)
o Green indicator light for memory card slot and USB plug slot
a USB plug slot
(behind the front cover)
s Display
d IR sensor for the remote control
f red LED STANDBY
g OPEN/CLOSE button
h Disc tray
j POWER button
B. DVD player rear panel
k
OPTICAL : optical digital audio output
l Y : Component video output
; PB/CB : Component video output
2) AUDIO OUT L : Left audio output
2! EURO SCART : Scart/RGB output
2@ CENTER : Output for front and centre audio channels
2# SL : Output for rear left audio channel
2$ FL : Output for front left audio channel
2% VGA : VGA video output
