KF-OB Parts list Rev A
Ref #
Part #
description
Qty
1
223-00967 UPRIGHT, RIGHT KF-OB
1
2
223-00968 UPRIGHT, LEFT KF-OB
1
3
223-00970 CROSS FRAME, KF-OB
1
4
223-00969 MAIN FRAME, KF-OB
1
5
223-00971 GUIDE FRAME, KF-OB
1
6
219-00492 DECLINE HANDLE, KF-OB
1
7
223-00972 ADJUSTABLE WEIGHT SUPPORT, KF-OB
2
8
223-00973 CARRIAGE, KF-OB
1
9
223-00974 SUPPORT, BACK PAD KF-OB
1
10
223-00974 SUPPORT, BACK PAD KF-OB
1
11
210-00015 ADJ PIN FOR SEAT
1
12
228-00221 BACK PAD, UPPER KF-OB
1
13
228-00222 SEAT PAD, KF-OB
1
14
206-00467 BALL HEAD, KF-OB
1
15
210-00022 KNOB BOLT M12*25
1
16
210-00021 POP PIN
2
17
223-00975 SUPPORT BAR, KF-OB
1
18
219-00493 SQUARE PLATE, KF-OB
2
19
206-00103 LAT BAR GRIP - KPS
1
20
206-00392 FOOT CAP, RIGHT 50.8 KF SERIES
4
21
206-00035 PLASTIC SLEEVE, 63.5X50.8
2
22
206-00029 PLASTIC SLEEVE 50.8*76.2
2
23
206-00391 SQUARE PLUG, 50.8 KF SERIES
6
24
206-00023 END CAP KPS-OB
1
25
206-00182 PLUG 38
2
26
202-00023 BRONZE BUSHING, ID 12.2
6
27
202-00118 SPRING
1
28
210-00146 U PIN, KPS-HCL, KPS-LEGA, KPS-OB
1
29
202-00685 SCREW, BUTTON HD SOCKET CAP M12X90
2
30
202-00686 SCREW, BUTTON HD SOCKET CAP M12X85
1
31
202-00687 SCREW, BUTTON HD SOCKET CAP M12X80
6
32
202-00640 SCREW, M12X80 BUTTON HEAD SOCKET CAP
1
33
202-00665 SCREW, BUTTON HEAD SOCKET CAP M10X65
2
34
202-00688 SCREW, FLAT SOCKET HD M10X25
4
35
202-00092 NYLON NUT, M12
10
36
202-00091 NYLON NUT, M10
1
37
202-00222 WASHER, 13X26X2 KPSFI #32
19
38
202-00223 WASHER, 11X23X2
4
39
206-00114 PLASTIC SLEEVE, 50.8x44.5
1
40
210-00034 LONG POP PIN, KPS-OB/KPS-1800
1
41
202-00636 SCREW, M8X25 BUTTON HEAD SOCKET CAP
9
42
202-00224 WASHER, 9X16X1.6
9
43
206-00022 RUBBER BUMPER KPS-OB #43
1
44
228-00223 BACK PAD, LOWER KF-OB
1
45
206-00393 FOOT CAP, LEFT 50.8 KF SERIES
4
#
202-00689 BOLT PACK, KF-OB
1
