16
Preparations
DVF-3530 / DV-402
The keys on the remote control unit with the same names as on the
main unit have the same function as the keys on the main unit.
1 POWER (
) key &
Power ON/OFF switching is ex-
ecuted.
2 RANDOM key ∞
3 AUDIO key ¡
4 ANGLE key ™
TOP MENU key &
5 MENU key &
6 ENTRE key (
7 ON SCREEN key (
8 Back skip (4 4 4 4 4) /PREV (Previ-
ous) key *
Forward skip ( ¢ ¢ ¢ ¢ ¢) /NEXT key
*
9 SLOW (Back slow/Forward slow)
keys *
0 STOP (7 7 7 7 7) key &
! Numeric keys )
Loading batteries
2 Insert batteries. 3 Close the cover. 1 Remove the cover.
÷ Insert two R03/LR03 (“AAA”-size) bat-
teries following the polarity indications.
Operation
Insert the power plug into a power outlet, press the POWER
key of the main unit to ON, then press the desired remote
control key.
÷ When pressing more than one remote control keys successively,
press the keys securely by leaving an interval of 1 second or more
between pressing of keys.
Operating range (approx.)
Remote sensor
1. The provided batteries are intended for use in operation checking, and their service life may be short.
2. When the remote controllable distance becomes short, replace both of the batteries with new ones.
3. If direct sunlight or the light of a high- frequency fluorescent lamp (inverter type, etc.) is incident to the remote sensor, malfunction
may occur. In such a case, change the installation position to avoid malfunction.
Model : RC-D0306
Infrared ray system
Operation of remote control unit
1
2
3
4
5
6
7
8
9
0
!
@
#
$
%
^
&
*
(
)
¡
™
£
@ P.MODE key §
# REPEAT key ¢
A-B Repeat key ¢
$ OPEN/CLOSE (0 0 0 0 0) key &
% DIMMER key fi
^ SUB TITLE key ¡
(SUB TITLE) ON/OFF key ¡
& Cursor Up (5 5 5 5 5), Down (∞ ∞ ∞ ∞ ∞), Left
( 2 2 2 2 2) and Right (3 3 3 3 3) keys (
* RETURN key (
( 1 1 1 1 1 (REV) key *
¡ ¡ ¡ ¡ ¡ (FF) key *
) STEP (Back step/Forward step)
keys *
¡ PLAY (3 3 3 3 3) key &
™ PAUSE (8 8 8 8 8) key &
£ CLEAR key (
Notes Notes
POWER 0
7 6
30º
30º
6m
