CABINET PARTS
2
For Model: KBLC36FTS00
(Stainless Steel)
W10138253
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
2320682 Use & Care Guide
2309438 Energy Guide
2309310 Service & Wiring
Sheet
2324934 Main Control
Service Sheet
628370 Modular Icemaker
Service Sheet
2320680 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 2307584 Grommet, Crossover
Tube
4 W10138054 Roller,
Front & Rear (4)
5 Support, Leveler
Assembly
2318194 Refrigerator Side
2318193 Freezer Side
8 8281164 Screw
9 2307640 Mounting Bracket,
Grill
11 2005921 Screw
12 W10129069 Clip (4)
13
2314064 Tube, Drain
15 487415 Screw, 8−18 x 3/8
16 2305274 Clamp, Tube
18 2257644 Hinge, Door
Refrigerator Top
19 2005783 Cam−Closer,
Door
20 2221070 Clamp, Tube
21 2006617 Bracket,
Support Door
22 2300082 Bushing
23 2260526 Housing,
Water Filter
24 2004517 Spring,
Door Closure
25 486194 Screw
26 4396841 Filter, Water
27 2266880 Bushing−Arm,
Extension
28 2318190 Bracket, Mounting
(Filter)
29 2005101 Hinge, Bottom
Refrigerator Door
30 489464 Screw, 8−18 x 1/2
31 489282 Screw
32 2209024B Skirt, Grille
(Bottom)
33 2006346 Washer
34 2325187B Grille Base,
Front
35 2215612 Cover, Air Duct
36 2266881 Arm, Extension
37 2221096 Bracket, Switch
38 2215938 Cover, Switch
39 2260518B Cap, Water Filter
40 8533913 Screw
41 1118894 Switch,
Rocker Arm (2)
42 W10005050 Screw, 8−18 x 1/2
43
8281163 Screw, 8−16 x 1/2
44 2260503B Button, Filter
45 2318189 Tray, Drip
Filter
46 2006388 Gap, Cover BTM
