KITCHENAID KBLC36FTS00 - Manual (Page 14)

FREEZER DOOR AND BASKET PARTS
14
For Model: KBLC36FTS00
(Stainless Steel)
W10138253
Illus. Part
No. No. DESCRIPTION
1 2327401 Freezer Door
Panel (Includes
Item 9)
2 2317101 Divider,
Basket (2)
3 2314025 Mat, Basket
4 W10135775 Screw, 5/16 x 3/4
5 W10135792 Screw, 8/32 x 1/4
6
2316868 Handle
7 2300025 Spacer, Door Edge
(Side)
8 2300027 Spacer, Door Edge
(Top & Bottom)
9 2300185 Door Gasket,
Magnetic
11 2306489 Skin, Door
12 2306398 Plate, Door
13 8281250 Screw, 8−15 x 1/2
14 2327533 Basket Assembly,
Freezer
15 2207454 Nut, Hex
16 W10001190 Washer
17 W10109030 Screw, 10−24 x 1/4
(Basket to Slide)
18 308544 Screw
19 2327468 Filler, Foam
