Technical Features
59
Accessories
1 Infrared remote control
2 Batteries 1.5 V, type: LR 03, size: AAA (Micro)
1 SCART cable
1 Set of operating instructions
1 Infrared mouse (ext. IR receiver)
SCART socket assignments
Signal
Pin No.
TV
Audio output, right
1
X
Audio input, right
2
Audio output, left
3
X
Audio earth
4
X
Blue earth
5
X
Audio input, left
6
Blue signal
7
X
Switching voltage
8
X
Green earth
9
X
Data signal
10
Green signal
11
X
Data signal
12
Red earth
13
X
Data earth
14
Red signal (C)
15
X
Blanking signal
16
X
Video earth
17
X
Blanking signal earth
18
X
Video output (FBAS/Y)
19
X
Video input
20
Connector shield
21
X
VHS/S-VHS changeover
The SCART socket can be switched over between VHS and S-VHS.
The changeover is executed in the "system parameters / A/V mode”
menu.
VHS (RGB):
the RED signal is applied at terminal 15,
the FBAS output is applied at terminal 19.
S-VHS (C/Y):
the C output is applied at terminal 15,
the Y output is applied at terminal 19.
