Installation

Pay attention to the help
information on the
individual menu items
you can obtain by

pressing the



button!

Antenna set-up

The menu item "Antenna set-up" can help you to align your antenna.

Here you will see various technical data that are intended for service
purposes only. The entries with the network name and reception
channel are of importance to you.

Here "Berlin" and "CH 43".

If you are already receiving a signal, you will see two bars in the left
column and "lock" next to the tuner entry.

You can now change the location of the antenna or in the case of a
directional antenna, turn the antenna slowly.

While doing so, observe the maximum of the left-hand bar and fix the
location of the antenna accordingly.
