7
PARTS LIST
Part
no.
Description
Qty.
Remarks
1 Left Base 1
2 Right Base 1
3 Ø 25 Short Foam Grip 6 Pre-assembled
4 Lower Support Bar 2
5 U-shape Bracket 2
6 Lower Upright Tube 2
7 Lower Cross Brace 1
8 1”Round Plug D25X1.5 2 Pre-assembled
9 Bottom Cross Brace 1
10 1”Round Plug D25X2 6 Pre-assembled
11 Upper Upright Tube 2
12 Upper Cross Brace 1
13 Extend Arm 2
14 Upper Support Bar 2
15 Ø 25 Mid Foam Grip 2 Pre-assembled
16 Ø 25 Long Foam Grip 1 Pre-assembled
17 Connective Head 2 Pre-assembled
18 Pull-up Bar 1
19 Armrest 2
20 Backrest Board 1
21 End Cap 4 Pre-assembled
22 2” Sq Sleeve 2 Pre-assembled
23 Protective Cover 2 Pre-assembled
A1 M10 x 20 Bolt 16
A2 M10 x 70 Bolt 18
A3 M10 x 55 Bolt 2
A4 M8 x 70 Bolt 4
A5 M8 x 40 Bolt 2
B1 Ø 10 Washer 54
B2 Ø 8 Washer 6
C1 M10 Aircraft Nut 18
