Motor and control parts – KITCHENAID KSM150PSGR0 User Manual
Page 9
MOTOR AND CONTROL PARTS
8212010
For Models: KSM150PS_ _0, 4KSM150PS_ _0
9
Illus. Part
No. No. DESCRIPTION
1
110679 Screw, Pivot
2
116241 Washer, Spring
3
Lever, Speed
Control Assy
9709276 Black
3184194 White on White
3184195 Almond Creme
4
3183680 Spring, Control
Plate
5
9704324 Washer, Ball
Bearing (Front)
6
9708315 Armature & Bearing
7
3180162 Washer
8
16998 Stud, Governor
Drive
9
3180526 Bracket, Bearing
Assembly
10
240775−1 Seal, End
11 W10131078 Nut
12
3180238 Washer
13
240769 Screw
14 W10068270 Washer
15
3184176 Speed Link & Cam
16
240205 Spring, Flat
17
9702695 Field Assembly
18
4162634 Sleeve, Motor Stud
19
9706416 Brush, Carbon
20
9707926 Screw, Set
21
4162546 Brush Holder
22
3179908 Housing, Brush
Holder
23
240680 Insert, Brush
Holder
24
116286 Cap, Spring Seat
25
116287 Spring, Cap
26
Cap, Brush Holder
3184212 Black
3184211 White
3184213 Almond Creme
27 W10068260 Screw
28
240904−2 Control Plate Assy
29
17830 Governor Assembly
30
9706595 Phase Control Brd
31
Cord, Power
W10164882 White
W10164883 Black
32
3184609 Screw, Self Tap
