CASE, GEARING AND PLANETARY UNIT
7
8212010
For Models: KSM150PS_ _0, 4KSM150PS_ _0
Illus. Part
No. No. DESCRIPTION
1
Gearcase Motor
Housing
2
Cap, Attachment
Hub
242765−2 Chrome
242765−4 White
242765−5 Almond Creme
3
Thumb Screw
9709194 Black
240374−2 White (Storm Gray)
240374−3 Buff
4
Band, Trim
5
3180161 Washer
6 W10112253 Worm Gear
7
240308 Worm Gear Bracket
And Bearing
8
9705444 Pin
9
240210−2 Shaft & Pinion
10
9705130 Gear, Attachment
Hub Level
11
9709627 Bevel Pinion
Center Gear
12
240026 Shaft, Vertical
Center
13
240018−1 Pin (Vertical
Center Shaft)
14
9705443 Pin, Groove
15
4162324 Gasket, Transmissn
16
67500−55 O−Ring
17
3180163 Washer
18
Lower Gear Case
19
103994 Screw
20
4176067 Agitator Shaft
21
9703438 Ring
22
9704677 Pin, Groove
23
4162914 Screw
24
Cover, End
25
311932 Screw
26
3400022 Screw
27
240309−2 Worm Gear Bracket
and Gear
28
4160474 Center Shaft &
O−Ring
29
8533914 Washer, Spring
Lock
30
3400025 Screw
31
3400203 Screw, Set
32
9703903 Pinion, Gear
Agitator Shaft
33
9706090 Washer
34
Planetary
35
240285 Ring, Planetary
Drip
36
89411 Screw, Adjusting
37
9703904 Gear, Internal
Refer to Pages 2 thru 4
