Encore 3500-HRC Parts List
Page 19
Parts List - EC1500C
PART #
DESCRIPTION
QTY PART #
DESCRIPTION
QTY PART #
DESCRIPTION
QTY
0-0130
PULLEY MOLDEDPLASTIC 1.9"
1
02-0002A SPRING-DECK LIFT
4
02-0028
SWITCH-MAGNETIC LIKK-YIHAN
1
02-0022
NYLOCK NUT HEX 10-24
6
02-0004
SCREW-8x5/8 PHIL PH AB BLACK
40
02-0038
WRENCH-ALLEN 3/16 SHAFT ARM
1
02-0036
SCREW-PPH 8x 5/8 GREEN HEAD
2
02-0005
SCREW-8x5/8 PHIL HILO BLACK TPB
8
02-0099 WASHER-SFW3/8x7/8x1/8" THICK
1
02-0040
RETAINER-GUIDE TUBE
1
02-0006
BOLT-HEX 5/16-18x5 1/2 GRADE 5-ZP
1
02-0108
SCREW-PPH 10 X 5/8"
1
03-0004
WALKBOARD WAXED
1
02-0007
NUT-5/16-18 NYLOCK ZP
3
02-0113
SCREW-HWH SLOTTED 8-18 X 3/4" AB ZP
1
04-0004
BELT-POLY V 190J8
1
02-0008
BOLT-HEX 5/16-18x 3/4"GRADE 2-ZP
3
02-0123
WASHER-FENDER 1/4 X 1"
2
04-0008
BELT WALK SPLICED 18x105WW
1
02-0009
NUT-HEX 5/16 WIZ-FL-LK-ZP
3
02-0138
STARWASHER 1/4
1
05-0001
EXTRUSION-SIDE BOARD-DELUXE
2
02-0013
WASHER-LOCK 1/4"
8
02-0139
HEX NUT 1/4-20
1
05-0011
EXTRUSION-EN CAP JOINT
1
02-0014
HEX BOLT, 1/4-20x2 1/2"GRADE 5 ZP
11
06-0056
HOLDER-REMOTE SWITC
2
05-0014
BOTTOM PAN JOINT 21 1/2
2
02-0015
SPRING WASHER
4
06-0058
SUPPORT-PC BOARD-HRC
4
06-0004
PLUG-BASE 1.5x3"-16GA
2
02-0016
HEX BOLT 3/8-16x2 1/2" GRADE 5
1
08-0027
SWITCH-REMOTE-HARNESS
2
06-0005
PLUG-DOME 1.5-16G
2
02-0017
NYLOCK HEX NUT 3/8-16
3
10-0012
BUMBER LATCH
1
06-0008
ENCAP
1
02-0018
PUSH NUT 3/8 HAT BLACK 375012
4
10-0017
TAPE-FOAM-1" X 75FT
1
06-0009
GLIDE-BASE EXTENSION
4
02-0019
CARRIAGE BOLT 10-24x1 1/2"
4
10-0020
GRIP MOLDED RUND
2
06-0012
WHEEL 3"
2
02-0020
SCREW-SHCS 1/4-20x2 1/2"
2
10-0024
TAPE-ADHESIVE 1'X18ft st567
1
06-0014
BUSHING-STRAIN RELIEF #1237
1
02-0021
WASHER-9/32 5/8 1/8 THICK ZP
2
11-0002
BUSHING-REAR ELEVATION
2
06-0016
WIRE TIES
12
02-0024
CARRIAGE BOLT 5/16 X 1GRADE 5 ZP
2
11-0003
BUSHING-UPRIGH POVOT
2
06-0019
CENTER BASE PAN
1
02-0025
WHEEL AXLE 2"
2
11-0017
AXLE FR 2" SNAP WHEEL
2
06-0020
END BASE PAN
1
02-0027
NUT-T HF 14209H-DB
8
14-0003
DECAL-MOTOR COVER SES-ALL-GRAY
1
06-0021
CLAMP-WIRE 3367 7/16
1
02-0031
HEX BOLT, 3/8-16 X 1 3/4 GRADE 5 ZP
2
14-0023
DECAL-NO LIFT - ALL FOLDS
1
06-0022
GUIDE-RESET TUBE
1
02-0033
WASHER-#10 EXTERNAL STAT
1
14-0024
DECAL-SAFETY LATCH-ALL FOLDS
1
06-0024
CLIP-ALLEN WRENCH
1
02-0041
SCREW-PPH 8-18x5/8" S/D-FOOTLATCH
1
14-0025
DECAL-WARNING FOLDING-ALL FOLDS
1
06-0025
MOTOR COVER CSA
1
02-0050
NUT-NYLOCK HEX 1/4-20
1
14-0289
STICKER HEART RATE ACUMEN
1
06-0026
FRONT BOTTOM PAN-CSA
1
02-0051
SCREW-SH CAP 10-24x1 1/4"
2
16-0001
BOX TOP
1
06-0059
COVER-HC RECEIVER-KEYS SERIES
1
02-0053
SCREW-SHCS 1/4-20x3/4"
2
16-0002
BOX BOTTOM
1
06-0084
BAG-PLASTIC 12 X 12 3 MIL-INST PACKET
1
02-0054
SCREW-HWH MACH 8-32x3/8"
1
16-0003
PAD-FRONT WHEEL
2
06-0125
SPACER U/R BLACK 9/16"
2
02-0068
WASHER-FLAT SAE 5/16
2
16-0004
PAD-REAR
1
06-0125
SPACER FOR UPRIGHT
2
02-0081
SCREW #4x3/8"PFST-READ SWITCH
8
16-0027
PAD-UPRIGHT
1
06-0130
PULLEY 8 GROOVE-190JA
1
02-0092
SCREW-PHTR#8x3/4" AB BLACK
7
16-0027
PAD-UPRIGHT-BB
1
06-0133
WHEEL-ROLLER 2"
4
02-0141
PUSH NUT BLAC .112 SHAFT
10
17-0035
RND1 1/2x16GAx16 1/2
2
08-0050
CONTROLLER REPLACES 08-0013
1
06-0027
COVER-PIVOT TB
2
18-0003
LINKAGE-BASE EXTENSION-RIGHT
1
09-0013
ROLLER-REAR 20MM SHAFT
1
06-0079
FAN-MCM MOTOR-5" W/1/2"SHAFT
1
18-0004
LINKAGE-BASE EXTENSION-LEFT
1
10-0002
ISOLATOR BOARD
8
06-0088
SLEEVE-MOTOR TENSION 1/4"
1
18-0006
SPRING-MOTOR TENSION-PRESET
1
10-0003
FOAM GRIP 1.5x14.75
2
06-0117
SWITCH HOUSING RUND GRAY
2
19-0010
BRACKET-UPRIGHT PIVOT
2
10-0004
RUBBER FOOT
2
06-0133
WHEEL 2" SNAP
4
19-0013
LATCH-FOOT LOCKING MECHANISM
1
12-0022
ACTUATOR 400LB MAYTECH
1
07-0041
CHEST STRAP NO LOGO ALL HR UNITS
1
19-0015
BRKT-MOTOR COVER
7
12-0033
MOTOR MCM 2.5HP
1
08-0004
CIRCUIT BREAKER 15AMP
1
19-0023
BRACKET UNIVERSAL
2
13-0003
HARNESS-ENCODER
1
08-0047
ENCODER-OPTICAL-ALEPH
1
19-0027
BRKT-PIVT TUBE
2
13-0011
POWER CORD-90"
1
08-0077
CORE-FERRITE
1
19-0096
BRACKET-H RECEIVER MOUNTING
1
13-0017
HARNESS-ELCO-HRC
1
13-0007
WIRE-BREAKER 6"
1
19-0134
BRKT BASE ELEVATION
1
14-0022
DECAL-MOTOR COVER-EC3500H-TEAL
1
13-0016
HARNESS-CONTROL PANEL
1
19-0159
BRKT MTOR SUPPORT REVISED 19-0005
2
14-0027
DECAL-EMERGENCY STOP-RED
1
14-0026
DECAL-WARNING CONSOLE-ALL-GRAY
1
20-0003
PROC-ACTUATOR EXT. TB-17-0011
1
14-0028
DECAL-CIRCUIT BREAKER-ALL
1
14-0204
DECAL-OPERATION INSTALL
1
20-0008
PROC-BASE EXTENSION TB 17-0010
2
14-0069
DECAL-END CAP LOGO-BLK/TEAL/RED
2
14-0205
DECAL-DISCONNECT-MOTOR COVER
1
20-0073
HANDLE BARS W/REMOTE 17-0035
2
14-0089
DECAL-STARBURST-WASDECK-YELLOW
2
15-0010
WARRANTY CARD 3/2/1-EC920/MS760
1
20-0086
PROC UPRIGHT TUE LT & RT 17-0062
2
15-0007
MANUAL EC3500HRC
1
19-0097
BRKT-ENCODER-MCMILLIAN
1
21-0018
CONSOLE PLATE-PUNCHED(19-0012)
1
15-0029
WIRING DIAGRAM MAGNETEK
1
22-0001
ACTUATOR CONNECTION ASSEMBLY
1
21-0037
UPRIGHT TUBE-SAW ANGLE CUT(4PC)
2
19-0019
GUIDE BELT GALVANIZED
2
22-0068
BASE FRAME WELDED SB-ASSEMBLY
1
23-0001
DECK FRAME ASSEMBLY
1
19-0032
BRKT-SPRING ANCHOR
2
24-0006
FRONT ROLLER-20MM SHAFT
1
23-0003
REAR ELEVATION ASSEMBLY-WELDED
1
19-0107
SLUG-EMERGENCY STOP
1
26-0046
INST PACKET EC3500HRC
1
23-0090
UPRIGHT ASSEMBLY
1
24-0110
COMPLETE CONSOLE ASSEMBLY
1
23-0092
U/R ASSEMBLY 4" W/TOGGES & HRC
1
