15
SECTION
FOUR
Anatomy of the Evolution 202
This section describes the Evolution 202 Preamplifier functions.
Figure 1 Evolution 202 Preamplifier and Power Supply Front Panels
1 Power Button
7 Stand-by/Power LED
2 Infrared Emitter
4 Infrared Sensor
3 Front Panel Display
5 Menu Button
6 Enter Button
8 Single-ended Input
Selection Buttons
9 Balanced Input
Selection Buttons
10 CAST Input Selection Buttons
11 Tape Button and LED
12 Mute Button and LED
13 Phase Button and LED
14 Level Control Knob
Inset Preamplifier and Power Supply:
Stacked View
