Kettler R-400 ROWER 7976-400 User Manual
Page 14
G-7
FLAT WASHERφ8.5xφ25x1t
1 PCS
G-8
FLAT WASHERφ8xφ16x1t
1 PCS
G-9
NYLON NUT M8
1
PCS
G-10
SPRING FOR IDLER WHEEL
1
PCS
H~H-20 SPRING
BOX
1
SET
H
SPRING BOX
1
PCS
H-1
SPRING 1
PCS
H-2
FLYWHEEL AXLE
1
PCS
H-3
SCREW M4x5L
1
PCS
H-4
FIXING PIN
1
PCS
H-5
COVER OF SPRING BOX
1
PCS
H-6
SCREW M4*12L
4
PCS
H-7
BUSHING φ10xφ14x3mmL
1 PCS
H-8
NUT 3/8"-26x4.5t
3
PCS
H-9
FIXING PIN
1
PCS
H-10
NUT 2
PCS
H-11
BEARING # 6000RS 1
PCS
H-12
IRON RING(1)
1
PCS
H-13
SCREW M5xP0.8x12L
2
PCS
H-14
IRON RING(2)
1
PCS
H-15
BEARNG #6203
1
PCS
H-16
ONE WAY BEARING
1
SET
H-17
PULLEY 1
PCS
H-18
BEARING #6003RS
1
PCS
H-19
FLAT WASHERφ30xφ34x1t
1 PCS
H-20
BEARING #6300RS
1
PCS
I-1 SCREW
M8*P1.25*16L(6m/m)
8
PCS
I-2 FLAT
WASHER
φ8*φ19*2T
8
PCS
I-3 SCREW
M5xP0.8x12L
8
PCS
I-4 SCREW
M5*P0.8*10L
4
PCS
J PEDAL
HOLDER
1
SET
J-1 STOPPER
1
PCS
J-2 SCREW
M5x25L
2
PCS
J-3 PEDAL
2
PCS
J-4 PAD
OF
PEDAL
2
PCS
J-5 PEDAL
STRAP
2
PCS
K ROLLING
SLIDER
1
SET
K-1 SEAT
1
PCS
K-2 ROLLER
4
SET
K-3
NLYON NUT M8
4
SET
L~L-6 MAGNETIC
SET
1
SET
L
MAGNETIC BRACKET
1
PCS
L-1
NYLON NUT M6
2
PCS
L-2
FLAT WASHERφ6xφ13x1t
2 PCS
L-3
CURVED WASHERφ12.5xφ18x0.3t
1 PCS
L-4
AXLE FORMAGNETIC SOCKET
1
PCS
