Parts List ROWER MACHINE
No.
Description
Quantity
A COMPUTER
1
SET
A-1 SCREW
FOR
FIXING
COMPUTER
4
PCS
B
SUPPORTING TUBE FOR BRACKET
1
PCS
B-1
BRACKET FOR FIXING COMPUTER
1
PCS
B-2
SCREW
2
PCS
B-3
FIXING CAP
4
PCS
B-4
FLAT WASHER φ6xφ16x1t
2
PCS
B-5
NYLON NUT M6
2
PCS
B-6
HEXAGONAL NUT M6xP1.0x57L
1
PCS
C
BRACKET FOR ROLLER
1
SET
C-1
DRIVING PULLEY
1
SET
C-2
ROLLER
1
SET
C-3
SCREW
1
PCS
C-4
SCREW M6x50L
1
PCS
C-5
NYLON NUT 3/8"x7t
1
PCS
C-6
NYLON NUT M6
1
PCS
C-7
SCREW M8xP1.25x35L(6m/m)
2
PCS
C-8
FLAT WASHER φ8*φ19*2T
2
PCS
C-9
BUSHING φ10xφ14x6mmL
2
PCS
C-10
BUSHING φ6xφ8.5x3mmL
4
PCS
C-11
FLAT WASHER φ6xφ16x1t
1
PCS
C-12
FLAT WASHER φ10xφ18x1t
1
PCS
D
MAIN FRAME
1
SET
D-1
CAP FOR FRONT STABLILZER(LEFT)
1
PCS
D-2
CAP FOR FRONT STABLILZER(RIGHT)
1
PCS
D-3
SUPPORTING CAP(LEFT)
1
PCS
D-4
SUPPORTING CAP(RIGHT)
1
PCS
D-5
ADJUSTING CAP
2
PCS
D-6
HEXAGONAL SCREW 3/8"-16x3t
2
PCS
D-7
TRANSPORTATION WHEEL
2
PCS
D-8
C-TYPE RING φ8 2
PCS
D-9
SPEEDY NUT M8
2
PCS
D-10
SENSOR BOX
2
SET
D-11
SCREW M4x10L
2
PCS
D-12
GEAR BOX
1
PCS
D-13
SCREW M8*P1.25*16L(6m/m)
8
PCS
D-14
FLAT WASHER φ8*φ19*2T 8
PCS
D-15
FRONT CAP FOR SLIDER
1
PCS
D-16
SCREW M5x10L
8
PCS
D-17L
LEFT COVER(LOWER)
1
PCS
D-17R
RIGHT COVER(LOWER)
1
PCS
D-18
SCREW 3/16"（#10）x3/4"
2 PCS
D-19 SCREW
M4x50L
3
PCS
D-20L SIDE
COVER(LEFT)
1
PCS
