Operation
Menu System – All Users
TX Frequency:
Transmitting frequency in MHz
Freq. offset:
Frequency offset between 0-1500 Hz.
Acc. offset:
Acc offset between 0-1500 Hz.
AGC:
AGC between 0-1024.
Gain:
Gain between 0-256.
TX level:
TX level equals LOW or OK.
Lo1-Lo3:
Lox In or Out of lock.
Temperature:
Temperature in deg. C.
Power mode:
Power mode in sleep or normal.
Bulletin
Ocean Region:
AORW, AORE, POR or IOR.
NSR state:
Not initialized, initializing or initialized.
Type:
Mini-M or NG
Bulletin page 1-6: Page 1 to 255 or Invalid.
Spot beam ID:
Spot beam ID number between 1-255.
SU CC Rxed:
Between 0000-9999.
SU CC Txed: Between
0000-9999.
Antenna
The antenna information is divided into two parts: Front
End Unit and Antenna Control Unit and is primarily
intended for service use.
FEU:
Unit type:
Serial no.:
SW version:
Mode:
Power:
Temperature:
Cable
loss:
Reset
count:
Date:
If cable loss is 100%, it means that the cable loss
compensation is at its maximum, and may therefore not be
able to compensate fully for the cable loss. A cable with a
lower RF loss should be used.
