COOKTOP PARTS
2
For Models: KECC567KBL03, KECC567KSS03, KECC567KBT03, KECC567KWW03
(Black) (S.Steel) (Biscuit) (Designer White)
8186758
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
9759087 Installation
Instructions
9759386 Wiring Diagram
8285368 Use & Care Guide
9759133 Safe Cooking Tips
COOKTOP PARTS
2 Cooktop, Glass
8284892 Black
8284895 Biscuit
8284894 Designer White
8284896 S.Steel
3 246119 Screw
4 4455420 Bracket, Switch
Mounting
6 9759094 Spring Locator(8)
7 Switch, Infinite
3191049 Use W/1500W
Left Rear Burner
4456027 Use W/1800/1000W
Right Rear Burner
3191049 Use W/1200W
Right Front Burner
4456027 Use W/1000/2400W
4456028 Jumper Wire
Left Front Burner
3191049 Use W/1400W
Center Rear Burner
8 3192439 Seal, Switch Shaft
9 3191945 Light, Indicator
10 Knob, Control (4)
9750372FF Black
9750372FW White
9750372FC Biscuit
11 4456521 Box, Burner
12 4455917 Bracket, Mounting
13 3400093 Screw
14 3196537 Screw
15 8285469 Seal, Switch (5)
16 8284628 Frame, Cooktop
(S.Steel model
only)
17 311865 Screw
20 9763517 Rail, Element (2)
21 3192269 Rail, Element (1)
22 3192222 Lamp, Hot
Surface Indicator
24 Element, Surface
4453909 1200/2400W − LF
4452742 1200W − RF
8523697 1500W − CR
4456507 1000/1800W − RR
8523697 1500W − LR
3183956 Seal, Switch
Cover
